Schneider Electric Motor Control Contactor LC1D 4-Pole 20A 415V, 400V AC Coil, 4 NO Terminals
Specifications
| Country of Origin | India |
|---|---|
| Brand | Schneider Electric |
| Function | Motor Control, Resistive Load |
| Length | 85mm |
| Model | LC1D |
| Depth | 92mm |
| Width | 45mm |
| Mount Type | DIN Rail |
| Series | LC1D |
| Maximum Operating Temperature | 60°C |
| Minimum Operating Temperature | -5°C |
| Terminal type | Screw |
| Number of Poles | 4 |
| Standards/Approvals | UL, CSA |
| Contact Voltage | 690V ac/dc |
| Coil Voltage | 400V ac |
| Normal State Configuration | 4 NO |
| Better World Claim | Designed for Disassembly |
| Contact Current | 20A |
| Number of Auxiliary Contacts | 2 |
| Auxiliary Contact Configuration | 1 NO |
| Operational Current Ie | 20A |
| Control Circuit Voltage Uc | 415V |
| Contactor Application | Resistive Load |
| Pole and Throw Configuration | 4 |
| Screw connections | IP20 finger-safe terminals with both North American and International terminal markings |
| AC-1 | This applies to all AC devices with a power factor of at least 0.95. Example of use: resistive load, heating, distribution |
| AC-3 | This applies to squirrel cage motors where breaking occurs while the motor is running. Example of use: all squirrel cage motors, lifts, escalators, conveyors, bucket elevators, compressors, pumps, mixers, air conditioning units |
Key Features
- Designed for motor control and resistive load applications.
- Equipped with 4 normally open (NO) contact terminals.
- Utilizes screw terminal connections with IP20 finger-safe design.
- DIN Rail mounting for easy integration in control panels.
- Rated for contact voltage up to 690V AC/DC and control circuit voltage of 415V.
- Operates reliably between -5°C to 60°C ambient temperature.
- Features 2 auxiliary contacts configured as 1 NO.
- Complies with UL and CSA standards for industrial safety and performance.
Product Description
Schneider Electric LC1DT20N7 is a high-quality TeSys D series motor control contactor featuring a 400V AC coil and 4-pole design, rated for 20A contact current at 415V control voltage. Its robust construction is ideal for motor control and resistive load applications in industrial, manufacturing, HVAC, and automation environments.
Equipped with four normally open (NO) contacts and two auxiliary contacts (one NO), this contactor supports flexible control circuit configurations. The screw type terminals offer IP20 finger-safe protection and are marked for both North American and international standards.
The contactor is suitable for mounting on DIN rail or panel mounting with screws, allowing easy installation and maintenance. It supports operational temperatures from -5°C to 60°C and withstands shocks and vibrations typical in industrial settings. Designed to meet UL and CSA safety certifications, it offers high reliability and compliance with international norms.
Its compact size with dimensions 85mm (length) x 45mm (width) x 92mm (depth) enables efficient space usage in control panels. The product supports the AC-1 and AC-3 utilization categories, making it versatile for resistive loads and squirrel cage motor applications such as lifts, conveyors, compressors, and pumps.
Designed for motor control and resistive load applications. 400V AC coil voltage and rated for 20A contact current. Four pole configuration with 4 NO terminals. Durable screw terminal connections with IP20 finger-safe protection.
Suitable for DIN rail or panel mounting. Operational temperature range from -5°C to 60°C. Compliant with UL and CSA industrial standards. Compact dimensions 85x45x92 mm for versatile installation. Includes 2 auxiliary contacts with 1 normally open configuration.
Designed for sustainability with disassembly claims.
Schneider Electric's TeSys D contactors such as the LC1DT20N7 are engineered to deliver long mechanical and electrical life, ensuring high reliability for demanding industrial applications. This contactor is an excellent choice for control systems requiring efficient and safe motor and load management.
Explore more contactors and control gear in the Electronics & Electricals Automation category at EnvMart.
Explore more products in our Electric Motors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The contactor has a contact current rating of 20A.
This model utilizes a coil voltage of 400V AC.
It can support a maximum contact voltage of 690V AC/DC.
The contactor is designed with a 4-pole configuration.
It features screw terminals that provide IP20 finger-safe protection.
It operates reliably within a temperature range of -5°C to 60°C.
It can be mounted on DIN rail or through panel mounting with screws.
The contactor includes 2 auxiliary contacts, configured as 1 normally open (NO).
It complies with UL and CSA standards for industrial safety and performance.
This contactor is suitable for motor control and resistive load applications, including lifts, conveyors, and compressors.
The dimensions are 85mm in length, 45mm in width, and 92mm in depth.
It is designed for motor control and resistive load applications.
