Bourns 6045 Shielded Wirewound Surface Mount Inductor 3.3 μH Semi Shielded ±30% 3.2 A SRN6045

Bourns SRN6045 Shielded Wirewound Surface Mount Inductor (Model: SRN6045) is a wirewound inductor with a ferrite core specifically designed for power electronics applications. It offers an inductance of 3.3 μH with a tolerance of ±30%, supporting a maximum DC current rating of 3.2 A. Its semi-shielded construction enhances electromagnetic compatibility.

The inductor comes in a compact 6045 package measuring 6mm in length, 6mm in depth, and 4.5mm in height, with solder termination for efficient surface mount assembly. Designed to meet RoHS compliance, it operates reliably in a temperature range from -40°C to 125°C, suitable for demanding environments.

This component's low DC resistance of 30 milliohms and a high maximum self-resonant frequency of 27 MHz allow it to perform efficiently in high-frequency circuits. The ferrite core ensures stable inductance and reduced core losses.

Applications for this inductor include automotive electronic systems such as driver assistance, lighting, entertainment, and information systems. It is also widely used in DC-DC converters, power supplies, televisions, and digital video equipment.

Features a ferrite core enhancing magnetic performance. Constructed as a wirewound surface mount inductor suitable for high current applications. RoHS compliant and uses solder termination style for reliable mounting. Designed to operate between -40°C and 125°C for robust thermal performance.

Has a compact 6045 package size with dimensions 6mm length, 6mm depth, and 4.5mm height. Maximum DC resistance is 30 milliohms ensuring efficient current flow. Semi-shielded construction reduces electromagnetic interference.

Maximum self-resonant frequency is 27 MHz supporting high-frequency use cases. Ideal for automotive systems including driver assistance, information, lighting, and entertainment. Suitable for DC-DC converters, power supplies, televisions, and digital video applications.

These inductors support industrial, automotive, and consumer electronics manufacturing environments. Their compact design allows integration into high-density circuit boards requiring effective power management. For more components like Bourns SRN6045 inductors and other surface mount inductors, explore the full range at EnvMart.
