Muller Digital Surface Mount Timer Switch 230V 50-60Hz SC 24.10 PRO SC 24.10 PRO 230V 50-60HZ

Muller SC 24.10 PRO 230V 50-60HZ Digital Surface Mount Timer Switch is a precision industrial automation component designed for timing control applications. It is ideal for controlling lighting, heating, ventilation, and other industrial processes requiring accurate scheduling.

This digital timer features a single channel with a SPDT contact configuration and uses a quartz crystal for time base accuracy. Designed for mounting on DIN rails or walls, it offers space-saving installation with a compact footprint measuring 45 mm in height and 50 mm in depth.

The timer supports 46 memory spaces allowing complex switch programs including permanent by date and holiday functions. Manual override and a PIN code provide security and flexibility in operation. Its robust construction supports ambient temperatures ranging from -10°C to 50°C and protection class IP20.

This model includes advanced features like automatic daylight saving time adjustment, elapsed time and pulse counter functions, and external input for manual override. The high switching capacity up to 8A makes it suitable for a variety of industrial and commercial control tasks.

Manufactured in Germany, the SC 24.10 PRO timer is used in outdoor and street lighting, industrial process control, and HVAC automation systems. Its durable build and extensive approvals make it a reliable choice for demanding environments.

Single channel with SPDT contact configuration. Quartz crystal time base with 1-minute segment length. 46 memory spaces for programmable switching schedules. Manual override and PIN code security features. Supports permanent date and holiday programming.

Compact dimensions for DIN rail or wall mounting. Operating temperature range -10 to 50 degrees Celsius. Battery life of 4 years for reliable service. Explore a wide range of Muller automation and control products at EnvMart for your industrial and commercial timing needs.
