TE Connectivity Mini-Spring PCB Socket Female 6.5A 22 AWG Straight Beryllium Copper Alloy Contact 5050864-1
Specifications
| Country of Origin | India |
|---|---|
| Brand | TE Connectivity |
| Orientation | Straight |
| Current | 6.5A |
| Length | 6.53mm |
| Gender | Female |
| Housing Material | Copper |
| Contact Material | Beryllium Copper Alloy |
| Series | Mini-Spring |
| Termination Type | Solder |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 718-5183Brand: TE ConnectivityManufacturers Part No.: 5050864-1 |
| Contact Plating | Tin |
| Minimum Wire Size AWG | 20AWG |
| Maximum Wire Size AWG | 22AWG |
Key Features
- This Mini-Spring socket features a straight orientation for easy installation.
- Constructed with a beryllium copper alloy contact material for excellent electrical conductivity.
- The contact plating is tin for reliable solder termination and corrosion resistance.
- Supports wire sizes between 20 AWG minimum and 22 AWG maximum.
- Compact length of 6.53 mm suitable for space-constrained PCB layouts.
- Housing material is copper, ensuring durability and electrical performance.
- Termination is via soldering, compatible with standard PCB solder processes.
- Complies with standard requirements, although no specific standards or approvals are indicated.
Product Description
TE Connectivity 5050864-1 Mini-Spring PCB Socket is a female discrete socket designed for printed circuit boards in electronic and electrical applications. It provides reliable electrical connections with a current rating of 6.5 amps and supports wire sizes ranging from 20 to 22 AWG. The socket has a straight orientation that facilitates straightforward mounting and solder termination on PCB assemblies.
Manufactured with a beryllium copper alloy contact material, the socket offers excellent durability and conductivity. The contacts are plated with tin to enhance corrosion resistance and solderability.
The compact 6.53 mm length of this miniature spring socket allows integration into space-sensitive electronic designs, making it suitable for applications requiring tight circuit layouts. The copper housing material further supports electrical performance and mechanical stability.
This product does not carry specific certification or standards approvals but meets typical industry expectations for PCB discrete sockets. Ideal for use in industrial equipment, consumer electronics, and general electronic manufacturing processes.
This Mini-Spring socket features a straight orientation for easy installation. Constructed with beryllium copper alloy for durability and conductivity. Provides stable 6.5A current handling capacity. Supports wire sizes 20 AWG to 22 AWG.
Tin plating ensures corrosion resistance. Copper housing provides mechanical stability. Designed for solder termination on PCBs. Compact 6.53 mm length suits tight PCB layouts.
Explore the Electronics & Electricals category to find more connectors and electronic components that fit your project needs. TE Connectivity offers a broad range of reliable interconnect solutions for various industrial and commercial applications.
Explore more products in our Wire Terminals & Splices category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 6.5 amps, making it suitable for various electronic applications.
It supports wire sizes ranging from 20 AWG minimum to 22 AWG maximum.
The socket has a compact length of 6.53 mm, which is suitable for space-constrained PCB layouts.
The contacts are made from a beryllium copper alloy, which provides excellent electrical conductivity and durability.
Termination is done via soldering, making it compatible with standard PCB solder processes.
It features a straight orientation, which facilitates straightforward mounting on printed circuit boards.
The contacts are plated with tin, enhancing corrosion resistance and solderability.
The housing is made of copper, which supports electrical performance and mechanical stability.
This product does not carry specific certification or standards approvals, but it meets typical industry expectations for PCB discrete sockets.
It is suitable for use in industrial equipment, consumer electronics, and general electronic manufacturing processes.
This socket belongs to the Mini-Spring series, which is designed for discrete applications on PCBs.
The country of origin for this product is India.
