TE Connectivity MULTILOCK 070 Female Connector Housing 3.5 mm Pitch 20 Way 2 Row Straight 1-174960-1
Specifications
| Country of Origin | India |
|---|---|
| Brand | TE Connectivity |
| Orientation | Straight |
| Length | 46.7mm |
| Width | 15.8mm |
| Mount Type | Through Hole |
| Housing Material | Polybutylene Terephthalate |
| Series | MULTILOCK 070 |
| Interfaces | lance design |
| Number of Rows | 2 |
| Pitch | 3.5mm |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 712-2510PBrand: TE ConnectivityManufacturers Part No.: 1-174960-1 |
| Number of Contacts | 20 |
| Connector Gender | Female |
Key Features
- The housing features a compact and durable design ensuring long-lasting performance.
- It provides a high-density 3.5 mm pitch suitable for space-constrained applications.
- Constructed from polybutylene terephthalate material for robustness and heat resistance.
- Includes an integral double locking system securing contact retention under vibration.
- Designed with a housing lance that protects contacts from rocking action damage.
- Compatible with female crimp contacts and supports through-hole mounting.
- Offers reliable and secure wire-to-wire and wire-to-board electrical connections.
- Ideal for applications in powertrain, safety, convenience, and driver information automotive systems.
Product Description
TE Connectivity 1-174960-1 MULTILOCK 070 Female Connector Housing is a high-density automotive connector housing designed with a 3.5 mm pitch and 20 contact positions arranged in 2 rows with a straight orientation. Engineered from durable polybutylene terephthalate, it withstands demanding environments and protects wire connections against mechanical stresses common in automotive applications.
Its compact design ensures efficient use of space, ideal for modern automotive powertrain, safety, security, convenience, driver information, and body & chassis systems. The housing's integral double locking mechanism ensures secure contact retention, preventing partial insertions and enhancing connection reliability during vehicle operation.
The housing lance design protects contacts from damage caused by KOJIRI action (rocking motion during mating and unmating), extending connector life. This Connector Housing is intended for through-hole mounting and uses female crimp contacts for wire-to-wire and wire-to-board applications, supporting reliable electrical connections.
TE Connectivity's MULTILOCK 070 series is recognized for its ease of handling, miniaturized form factor, and high density, making it suitable for a broad range of automotive and industrial electrical systems. This particular housing supports 20 contacts in a 2-row configuration, providing flexibility for various wiring requirements.
The housing has a polybutylene terephthalate construction for durability. Incorporates an integral double locking system for secure contact retention. High-density 3.5 mm pitch supports compact wiring layouts. The design protects contacts from mechanical damage during connection cycles.
Available in straight orientation with through-hole mount type. Designed specifically for 20 contacts arranged over 2 rows. Supports automotive wire-to-wire and wire-to-board applications. Contributes to reliable and secure electrical connections in harsh environments.
Typical applications include automotive powertrain, safety, convenience, and chassis systems. Explore more about TE Connectivity connectors in the Electronics & Electricals category on EnvMart for reliable power and signal transmission solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This connector housing features a 3.5 mm pitch and supports 20 contacts arranged in 2 rows.
The housing is constructed from polybutylene terephthalate, which provides robustness and heat resistance.
It has a straight orientation and is designed for through-hole mounting.
Yes, it incorporates an integral double locking system that secures contact retention under vibration, preventing partial insertions.
It is suitable for automotive applications including powertrain, safety, convenience, and driver information systems.
The housing has a length of 46.7 mm and a width of 15.8 mm.
Yes, it is compatible with female crimp contacts for wire-to-wire and wire-to-board applications.
The housing features a lance design that protects contacts from rocking action damage during mating and unmating cycles.
This connector housing is part of the MULTILOCK 070 series by TE Connectivity.
The connector gender for this housing is female.
The country of origin for this connector housing is India.
The high-density design with a 3.5 mm pitch is suitable for space-constrained applications, allowing efficient use of space in automotive systems.
