Preci-Dip 4 Way Straight Through Hole 2.54 mm Pitch Socket Contact Carrier 100 V ac, 150 V dc, 3A 712-87-104-41-001101

Preci-Dip 712-87-104-41-001101 4 Way Straight Through Hole Socket Contact Carrier is designed for high precision electronic applications requiring robust performance with a compact form factor. It features a pitch of 2.54 mm suitable for standard IC socket mounting with a current rating of 3A at 100 V ac and 150 V dc, making it ideal for various industrial and laboratory electronics.

The socket contacts are fabricated from brass combined with a beryllium copper alloy to deliver excellent electrical conductivity and mechanical strength. Contacts are plated with gold and tin, enhancing corrosion resistance and ensuring a reliable connection over extensive use.

The straight orientation and through-hole mounting facilitate straightforward PCB assembly aligned with industry practices. The housing is constructed from fibreglass reinforced polycyclohexylenedimethylene terephthalate, a high-performance engineering plastic that withstands temperatures from as low as -55°C up to 125°C, assuring durability even in challenging environments.

Dimensions of this socket contact carrier are precisely controlled, measuring 10.16 mm in length, 1.83 mm in width, and 4.26 mm in depth, making it suitable for compact electronic assemblies with limited space. The individual solder tail length of 3.11 mm enables secure and stable solder joints on the PCB.

Four contacts made of brass and beryllium copper alloy ensure reliable conductivity. Gold and tin plating on contacts provide corrosion resistance and durability. Straight orientation and through-hole mounting allow easy PCB integration.

Fibreglass reinforced housing offers thermal and mechanical stability. Wide operating temperature range from -55°C to 125°C ensures robust performance. Compact dimensions with length, width, and depth optimized for space-constrained assemblies.

Supplied on disposable carriers for efficient and accurate solder mounting. Reliable socket contacts designed for mating pin diameters of 0.47 mm with zero profile design.

This product is manufactured in Switzerland and meets industrial standards for electronic connectors, suitable for applications in manufacturing, automotive electronics, telecommunications, and laboratory equipment.
