Ewellix Makers in Motion Linear Guide Carriage LLTHC 20 LA T0 P5 Series 24.4 kN Dynamic Load LLTHC 20 LA T0 P5
Specifications
| Country of Origin | Taiwan |
|---|---|
| Brand | Ewellix Makers in Motion |
| Model | LLTHC 20 LA T0 P5 |
| Series | LLTHC 20 LA T0 P5 |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 184-9738Brand: Ewellix Makers in MotionManufacturers Part No.: LLTHC 20 LA T0 P5 |
| Static Load Rating | 44.6kN |
| Dynamic Load Rating | 24.4kN |
| Carriage Length | 89.5mm |
| Carriage Width | 63mm |
| Acceptable Rail Width | 20mm |
Key Features
- Integrated side and inner seals provide contamination protection for enhanced durability.
- Equal load carrying capacity combined with top rigidity ensures stable performance.
- Rails with dual reference sides guarantee precise alignment and smooth operation.
- Low friction and wear result from high-quality surface finishing on rails for longer service life.
- Easy installation and adjustment require minimal maintenance over operational lifespan.
- Long, flanged carriage design available from size 20 to 45 enhances load rating and rigidity.
- Equipped with 4 large threaded holes for versatile mounting from top and bottom sides.
- Manufactured to meet quality requirements, suitable for industrial and mechanical automation uses.
Product Description
Ewellix Makers in Motion LLTHC 20 LA T0 P5 linear guide carriage is engineered to provide high precision and load capacity in mechanical and automation systems. This carriage belongs to the LLTHC 20 LA T0 P5 series with a dynamic load rating of 24.4 kiloNewtons and static load rating of 44.6 kiloNewtons.
The product features integrated side and inner seals within the carriage to protect the sliding components from contaminants, increasing durability and reliability in harsh environments. Rails have dual reference sides and a low roughness surface finish to ensure smooth, low-friction motion and accurate guidance.
The carriage measures 89.5 mm in length and 63 mm in width, designed for rails with an acceptable width of 20 mm. Its long flanged carriage design includes 4 larger threaded holes for flexible mounting options both from the top and bottom sides, making it highly adaptable for various industrial automation and manufacturing setups.
This Linear Guide Carriage is purpose-built for applications requiring precise, high-rigidity guidance with low maintenance, including industrial machinery, robotics, assembly lines, and automated material handling systems.
Integrated side and inner seals enhance protection against contamination. Equal load carrying capacity ensures consistent rigidity and performance. Dual reference side rails allow precise alignment and smooth movement. High-quality rail surface reduces friction and wear over long-term use.
Long, flanged carriage improves load handling and rigidity for heavy-duty applications. Four large threaded mounting holes provide easy installation options. Designed for linear motion in industrial automation and manufacturing settings.
Country of origin is Taiwan, Province Of China. This product is new and ready for delivery. Explore EnvMart’s Mechanical Machinery & Spares categories for more precision linear motion components and related industrial tools.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The dynamic load rating of this linear guide carriage is 24.4 kiloNewtons.
The static load rating for the LLTHC 20 LA T0 P5 is 44.6 kiloNewtons.
The carriage measures 89.5 mm in length and 63 mm in width.
This model is designed for rails with an acceptable width of 20 mm.
It features four large threaded holes that allow for versatile mounting from both the top and bottom sides, simplifying installation.
Integrated side and inner seals provide contamination protection, increasing the durability and reliability of the carriage in harsh environments.
It is suitable for applications requiring precise, high-rigidity guidance, including industrial machinery, robotics, assembly lines, and automated material handling systems.
Rails with dual reference sides and a low roughness surface finish ensure smooth, low-friction motion and accurate guidance.
The long, flanged carriage design enhances load handling and rigidity, making it suitable for heavy-duty applications.
This product is manufactured in Taiwan, Province Of China.
The design requires minimal maintenance over its operational lifespan, thanks to its low friction and wear characteristics.
The brand of this linear guide carriage is Ewellix Makers in Motion.
