RS PRO Pluggable Terminal Block 8-Contact 3.5 mm Pitch 1 Row 300V 8A Polyamide 66 Housing 144-4112
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 300V |
| Brand | RS PRO |
| Colour | Green |
| Orientation | Right Angle |
| Current | 8A |
| Length | 29.4mm |
| Model | 144-4112 |
| Depth | 9.2mm |
| Width | 7.2mm |
| Housing Material | Polyamide 66 |
| Number of Rows | 1 |
| Pitch | 3.5mm |
| Number of Contacts | 8 |
| Minimum Wire Size mm² | 0.32mm² |
| Maximum Wire Size mm² | 1.3mm² |
| Minimum Wire Size AWG | 28AWG |
| Maximum Wire Size AWG | 16AWG |
| Wire Connection Method | Screw |
| RS PRO Pluggable Terminal Block, 8-Contact, 3.5 mm Pitch, 1 RowBrand | RS PRO |
Key Features
- The terminal block features a green polyamide 66 housing with UL94-V0 flame retardant properties.
- Compatible with 28 AWG to 16 AWG wire sizes, accommodating solid and stranded cables from 0.32 mm² to 1.3 mm².
- Right angle orientation design allows for space-efficient PCB mounting.
- Professional rising clamp screw terminals provide secure wire connections with captive screws.
- Polarised mouldings and guided pin alignment ensure correct and easy mating of male-female connectors.
- Compact dimensions of 29.4 mm length, 7.2 mm width, and 9.2 mm depth suit various electronic assembly applications.
- Approved to UL and VDE standards for safety and reliability in industrial and commercial environments.
- Ideal for use in electronic, industrial automation, power connector, and instrumentation systems.
Product Description
RS PRO 144-4112 Pluggable Terminal Block is a professional-grade 8-contact terminal block with 3.5 mm pitch and a single-row configuration, rated for electrical applications up to 300V and 8A current. Built with a high-quality polyamide 66 housing, this terminal block offers excellent flame retardant properties compliant with UL94-V0 standards.
This component supports wire sizes from 28 AWG to 16 AWG (0.32 mm² to 1.3 mm²), suitable for both solid and stranded cables. It employs screw connection methods with captive screws and rising clamp terminals, ensuring secure and reliable electrical contacts. The right-angle orientation allows optimized PCB mounting, making it a compact solution for dense electronic circuits.
The terminal block features polarised mouldings and guided pin alignment for foolproof assembly with mating connectors. Its compact size of 29.4 mm length, 7.2 mm width, and 9.2 mm depth fits well in various electronic and industrial applications such as power distribution, control panels, instrumentation, and industrial automation systems.
The terminal block features a green polyamide 66 housing with UL94-V0 flame retardant properties. Compatible with 28 AWG to 16 AWG wire sizes, accommodating solid and stranded cables from 0.32 mm² to 1.3 mm². Right angle orientation design allows for space-efficient PCB mounting.
Professional rising clamp screw terminals provide secure wire connections with captive screws. Polarised mouldings and guided pin alignment ensure correct and easy mating of male-female connectors. Compact dimensions of 29.4 mm length, 7.2 mm width, and 9.2 mm depth suit various electronic assembly applications.
Approved to UL and VDE standards for safety and reliability in industrial and commercial environments. Ideal for use in electronic, industrial automation, power connector, and instrumentation systems.
This RS PRO pluggable terminal block is an essential component for diverse electronic and electrical projects requiring secure, reliable, and space-efficient wire termination. It is suitable for use across industrial, commercial, automation, and manufacturing sectors.
Browse more from RS PRO and explore extensive electronics components at EnvMart.
Explore more products in our Electronic Components, Power & Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for electrical applications up to 300V.
It accommodates wire sizes from 28 AWG to 16 AWG, or 0.32 mm² to 1.3 mm².
This unit employs screw connection methods with captive screws and rising clamp terminals.
The compact dimensions are 29.4 mm in length, 7.2 mm in width, and 9.2 mm in depth.
The right angle orientation design allows for space-efficient PCB mounting, optimizing space in electronic assemblies.
It is approved to UL and VDE standards for safety and reliability in industrial and commercial environments.
This model features 8 contacts in a single-row configuration.
It is ideal for use in electronic, industrial automation, power connector, and instrumentation systems.
Yes, it is compatible with both solid and stranded cables within the specified wire size range.
