TE Connectivity PCB Power Relay 6V DC Coil 8A Switching Current DPDT RX424006
Specifications
| Country of Origin | Austria |
|---|---|
| Brand | TE Connectivity |
| Dimensions | H 15.7mm, W 29.0mm, D 12.7mm |
| Height | 15.7mm |
| Length | 29mm |
| Model | RX424006 |
| Width | 12.7mm |
| Mount Type | PCB |
| Contact Material | Silver Nickel Alloy |
| Series | RX2 |
| Maximum Operating Temperature | 70°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 8A |
| Terminal type | Solder |
| Standards/Approvals | VDE, RoHS, IEC 60335-1 |
| Coil Resistance | 68Ω |
| Coil Voltage | 6V dc |
| Switching AC Voltage | 400V ac |
| Coil Power | 250mW |
Key Features
- Designed for PCB mounting with solder terminals.
- Operates within -40°C to 70°C temperature range.
- Contact material uses silver nickel alloy for reliable performance.
- Coil resistance rated at 68 ohms with 250mW coil power.
- Switching AC voltage capacity up to 400V AC.
- Complies with VDE, RoHS, and IEC 60335-1 standards.
- Suitable for domestic appliances, heating control, emergency lighting, and automatic doors.
Product Description
TE Connectivity RX424006 PCB Power Relay is a high-quality DPDT relay designed for through-hole mounting on printed circuit boards. It features a 6V DC coil voltage and supports a switching current of 8A. The relay is constructed with silver nickel alloy contacts and offers reinforced insulation for enhanced durability.
This relay has compact dimensions measuring 15.7mm in height, 29.0mm in length, and 12.7mm in width, making it suitable for space-constrained applications. It operates reliably in a temperature range from -40°C to 70°C, accommodating various environmental conditions.
The coil resistance of 68 ohms and coil power of 250mW ensure efficient operation with minimal heat generation. With a switching AC voltage rating of 400V AC, this relay is suitable for a range of electrical applications.
Typical industrial applications include domestic appliances, heating controls, emergency lighting systems, and automatic door mechanisms. The RX2 series relays come with flux-proof designs and white covers for protection, ensuring long-lasting performance in demanding environments.
Designed for PCB mounting with solder terminals. Compact size for integration into tight spaces. Robust silver nickel alloy contacts. High insulation and safety standards compliance. Wide operating temperature for versatile use.
Low coil power consumption. Suitable for various industrial and commercial electrical control applications.
Choose this TE Connectivity RX424006 PCB Power Relay for reliable and efficient switching solutions in your electrical and automation projects. Browse more Power Relays and related products at EnvMart to find compatible components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The RX424006 relay operates with a coil voltage of 6V DC.
This model supports a maximum switching current of 8A.
The relay measures 15.7mm in height, 29.0mm in length, and 12.7mm in width.
It operates reliably within a temperature range of -40°C to 70°C.
The RX424006 features a Double Pole Double Throw (DPDT) contact configuration.
The coil resistance is rated at 68 ohms.
It has a switching AC voltage capacity of up to 400V AC.
The contacts are made from a silver nickel alloy, providing reliable performance.
It complies with VDE, RoHS, and IEC 60335-1 standards.
This relay is designed for PCB mounting with solder terminals.
Typical applications include domestic appliances, heating controls, emergency lighting, and automatic doors.
The coil power consumption is rated at 250mW, ensuring efficient operation.
