Texas Instruments Analogue Switch CMOS Single SPDT 6-Pin SOT-323 TS5A3159DCKT
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 900μm |
| Length | 2mm |
| Model | TS5A3159DCKT |
| Width | 1.25mm |
| Mount Type | Surface |
| Output type | CMOS |
| Configuration | Single SPDT |
| Maximum Operating Temperature | 85°C |
| Package Type | SOT-323 |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS |
| Pin Count | 6 |
| Number of Elements per Chip | 1 |
| Maximum Supply Voltage | 5.5V |
| Logic Family | CMOS |
| Minimum Supply Voltage | 1.65V |
| Maximum On State Resistance | 1.5Ω |
Key Features
- Operates within a supply voltage range of 1.65V to 5.5V ensuring versatile application.
- Features low maximum on-state resistance of 1.5 ohms for efficient signal switching.
- Compact dimensions with 2mm length, 1.25mm width, and 900µm height enabling space-saving PCB designs.
- Wide operating temperature range from -40°C to 85°C suitable for industrial environments.
- Surface mount package type suitable for automated PCB assembly processes.
- Single element per chip supporting precise analogue signal switching.
- Meets RoHS standards ensuring environmental compliance.
- Designed for analogue signal routing and multiplexing applications in electronics.
Product Description
Texas Instruments TS5A3159DCKT analogue switch is a high-performance CMOS-based single SPDT device housed in a compact 6-pin SOT-323 surface mount package. It supports a supply voltage range from 1.65V to 5.5V and features a low on-state resistance of 1.5 ohms, making it suitable for a variety of analogue signal switching and multiplexing applications.
The device's small dimensions (2mm length, 1.25mm width, 900µm height) allow for efficient use of limited PCB space in complex circuitry. This analogue switch operates reliably over a wide temperature range from -40°C to 85°C, ensuring stable performance in demanding industrial and automotive applications.
Designed to isolate and route signals with precision, the TS5A3159DCKT simplifies signal routing and minimizes duplication of circuitry. Its CMOS technology guarantees low power consumption, making it ideal for battery-powered and energy-efficient devices.
This component adheres to RoHS standards, ensuring compliance with environmental safety regulations. It is extensively used in electronic components, power and connector semiconductor circuits, and logic IC applications.
Operates between 1.65V and 5.5V supply voltages. Maximum on-state resistance of just 1.5 ohms. Compact 6-pin SOT-323 surface mount package. Wide operating temperature from -40°C to 85°C. Single SPDT element per chip for precise signal switching.
RoHS compliant for environmental safety. Optimized CMOS performance for low power consumption. Applications include multiplexers, signal routing, and automotive electronics.
This analogue switch from Texas Instruments is an essential component for electronic circuit designers aiming for efficient, space-saving, and reliable switching solutions in industrial, automotive, and consumer electronics sectors. Explore the full range of Analogue Switches and multiplexer ICs available at EnvMart for your design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates within a supply voltage range of 1.65V to 5.5V.
It features a low maximum on-state resistance of 1.5 ohms, which facilitates efficient signal switching.
The device has compact dimensions of 2mm in length, 1.25mm in width, and 900µm in height, making it suitable for space-saving PCB designs.
It operates reliably over a wide temperature range from -40°C to 85°C, suitable for industrial environments.
This analogue switch is housed in a 6-pin SOT-323 surface mount package, which is suitable for automated PCB assembly processes.
The TS5A3159DCKT contains a single SPDT element per chip, allowing for precise analogue signal switching.
Yes, it meets RoHS standards, ensuring environmental compliance.
It provides a CMOS output type, which is optimized for low power consumption.
It is designed for analogue signal routing and multiplexing applications in electronics, including automotive and industrial uses.
This model belongs to the CMOS logic family, which is known for its low power requirements.
The TS5A3159DCKT has a pin count of 6, making it compact for various applications.
The country of origin for this device is India.
