Schneider Electric TeSys K 3-Pole Contactor 24V DC Coil 9A, 4kW 600V AC LP1K0901BD
Specifications
| Country of Origin | France |
|---|---|
| Brand | Schneider Electric |
| Function | Motor Control, Resistive Load |
| Length | 58mm |
| Model | LP1K0901BD |
| Depth | 57mm |
| Width | 45mm |
| Mount Type | DIN Rail |
| Series | LP1K |
| Power Rating | 4kW |
| Maximum Operating Temperature | 50°C |
| Minimum Operating Temperature | -25°C |
| Terminal type | Screw |
| Number of Poles | 3 |
| Standards/Approvals | UL, RoHS, IEC, EAC, CSA, CCC |
| Contact Voltage | 600V ac |
| Coil Voltage | 24V dc |
| Normal State Configuration | 3 NO |
| Better World Claim | Designed for Disassembly |
| Contact Current | 9A |
| Number of Auxiliary Contacts | 1 |
| Auxiliary Contact Configuration | 1 NC |
| Operational Current Ie | 20A |
| Control Circuit Voltage Uc | 24V dc |
| Contactor Application | Resistive Load, Motor Control |
| Pole and Throw Configuration | 3 |
Key Features
- Compact and DIN rail compatible for easy installation.
- Includes one normally closed auxiliary contact for integration to control systems.
- Designed for a wide operating temperature range from -25°C to 50°C.
- Screw clamp terminals ensure secure and quick connections.
- Mechanical lifespan of up to 10 million cycles for reliability.
- Suitable for motor systems, lighting networks, and automation equipment.
- Complies with multiple international standards including UL, IEC, CSA, and RoHS.
- Manufactured in France with a compact form factor of 58mm length, 45mm width, and 57mm depth.
Product Description
Schneider Electric LP1K0901BD is a compact and efficient 3-pole TeSys K contactor engineered for motor control and resistive load applications. Featuring a 24V DC coil and a 9A contact current, this device supports up to 4 kW power rating at 600V AC, making it suitable for a range of industrial and commercial automation systems.
The contactor boasts a robust DIN rail mount design that allows easy integration in tight control panels, with screw clamp terminals for straightforward wiring. It includes one normally closed auxiliary contact (1 NC) which facilitates enhanced control options and system interfacing.
Designed for demanding environments, the LP1K0901BD operates reliably over a broad temperature range from -25°C to 50°C. Its mechanical endurance guarantees up to 10 million operational cycles, providing long-term, trouble-free service in intensive industrial applications.
This compact contactor measures 58 mm in length, 45 mm in width, and 57 mm in depth, saving valuable panel space. It complies with multiple international standards such as UL, RoHS, IEC, EAC, CSA, CCC, and supports certifications for marine applications, ensuring wide acceptance and safety compliance worldwide.
Ideal for manufacturing, automation equipment, lighting networks, and motor systems, the Schneider Electric LP1K0901BD assures efficient performance within various industrial sectors. It can be complemented with auxiliary contact blocks and thermal relays for advanced motor control functionalities.
Compact size facilitates space-saving installation in control panels. DIN rail mounting with screw clamp terminals for quick assembly. Designed for motor and resistive load control applications. Wide temperature range operation from -25°C to 50°C for harsh environments.
High mechanical lifespan rated at 10 million cycles ensures durability. Included auxiliary contact enables flexible control system integration. Conforms with global safety and quality standards such as UL, IEC, and RoHS.
Manufactured in France, supporting high quality and reliability industry requirements.
Explore more Schneider Electric automation and control gear products on EnvMart for reliable and energy-efficient electrical solutions across industrial, manufacturing, HVAC, and commercial applications.
Explore more products in our Contactors & Auxiliary Contacts category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a power rating of 4 kW at 600V AC.
The contact current for the LP1K0901BD is 9A.
It features screw clamp terminals for secure and quick connections.
This contactor operates reliably within a temperature range of -25°C to 50°C.
This model is a 3-pole contactor.
It includes one normally closed (1 NC) auxiliary contact.
The LP1K0901BD is designed for DIN rail mounting.
This contactor measures 58 mm in length, 45 mm in width, and 57 mm in depth.
It is suitable for motor control and resistive load applications.
It complies with UL, RoHS, IEC, EAC, CSA, and CCC standards.
The mechanical lifespan of the LP1K0901BD is rated at up to 10 million cycles.
The coil voltage for this contactor is 24V DC.
