Schneider Electric CA3KN Contactor 10 A 690V AC Control Relay 2 NO/2 NC Screw Clamp Terminals CA3KN22ED

Schneider Electric CA3KN22ED contactor is a 10 A, 690V AC control relay designed for efficient electromagnetic load management. This relay features a contact configuration of 2 normally open (NO) and 2 normally closed (NC) contacts, delivering high reliability and performance for control applications.

The device offers a compact form factor with a 45mm width, making it suitable for clipping on standard 35mm DIN rails or fixing by screws. The screw clamp terminals ensure secure and consistent electrical connections. Rated for operation within ambient temperatures ranging from -25°C to 50°C, it provides dependable durability and resistance in diverse industrial environments.

Certified to international standards including IEC 60947-4-1, UL, CSA, CE, UKCA, and others, the CA3KN22ED model meets rigorous safety and performance criteria. It supports contact currents up to 10 A and voltages of 690V AC, making it suitable for controlling electromagnetic loads effectively. The relay incorporates a 48V DC control circuit with no inrush consumption, enabling energy-efficient operation.

With high operating rates up to 180 cycles per minute, this contactor is ideal for industrial, manufacturing, commercial automation, building infrastructure, and other control systems where noise sensitivity and supply disturbances may be a concern.

Operates under -25°C to 50°C ambient temperature range. Compact 45mm width housing for DIN rail or screw mounting. Contact configuration of 2 normally open and 2 normally closed contacts. Screw clamp terminal type for secure connections.

Certified to IEC, UL, CSA, CE, UKCA, and multiple global standards. Low power consumption control coil and suppressed inrush current. High cycle rate up to 180 cycles per minute. Designed for electromagnetic load control in industrial automation.

Set contains one Schneider Electric CA3KN22ED TeSys K series contactor.

This contactor is part of the Schneider Electric TeSys K range, renowned for seamless integration into diverse automation applications offering compactness and high performance. Explore more Schneider Electric control and automation devices on EnvMart for your industrial and commercial project needs.
