Schneider Electric Residual Current Device Acti9 Active iDT40 Series 40A 1-Pole 30 mA Voltage Independent 230V ac A9TYAE640

Schneider Electric A9TYAE640 Residual Current Device from the Acti9 Active iDT40 Series is a high-performance, voltage independent RCCB designed for precise earth leakage protection in electrical installations operating at 230V ac. With a rated current of 40A and a single-pole configuration, it effectively safeguards against leakage currents with a trip sensitivity of 30 mA to ensure user and equipment safety.

This device incorporates advanced tripping characteristics that are voltage independent, offering stable protection performance even with fluctuating supply voltages. The compact physical dimensions of 91mm height, 73mm depth, and 36mm width allow for seamless integration into existing circuit breaker panels.

It complies with rigorous international standards including EN/IEC 62606, EN/IEC 61009-1, and EN/IEC 61009-2-1, guaranteeing adherence to safety and performance benchmarks. The A-SI earth leakage protection type provides a higher level of sensitivity, suitable for residential, commercial, and industrial applications demanding reliable fault detection.

The product supports clip-on mounting and features an impulse withstand voltage of 4 kV alongside an electrical durability rated at 10000 cycles, ensuring long-term durability in diverse operating environments. Operation is guaranteed in ambient temperatures ranging from -25 °C to 60 °C with a relative humidity tolerance of up to 95% at 55 °C.

Manufactured in Spain by Schneider Electric, this RCCB is engineered to meet the highest industrial and domestic electrical safety requirements. Its design facilitates easy installation and maintenance, making it an ideal choice for upgrading or installing new circuit protection systems.

Designed for reliable earth leakage protection in residential and industrial electrical applications. Features voltage independent tripping characteristics ensuring stable operation under variable voltage conditions. Compact dimensions with height 91mm, depth 73mm, and width 36mm for easy installation.

Compliance with EN/IEC 62606, EN/IEC 61009-1, and EN/IEC 61009-2-1 safety standards. Rated current of 40A with 1-pole configuration suitable for single phase power systems. Rated AC voltage of 230V ac compatible with standard electrical installations.

Equipped with A-SI earth leakage protection type for enhanced sensitivity and safety. Manufactured in Spain ensuring high build quality and reliability.
