Honeywell Technologies Pin Plunger Micro Switch, Solder Terminal, 100mA Contact Current, 250V AC, SPDT, IP40 ZM110D10A01
Specifications
| Country of Origin | China |
|---|---|
| Brand | Honeywell |
| Length | 19.8mm |
| Model | ZM110D10A01 |
| Depth | 10.2mm |
| IP Rating | IP40 |
| Width | 6.4mm |
| Housing Material | PBT |
| Series | ZM1 |
| Maximum Operating Temperature | 125°C |
| Contact Configuration | SPDT |
| Actuator Type | Pin Plunger |
| Minimum Operating Temperature | -40°C |
| Terminal type | Solder |
| Switch Contact Current | 100mA |
| Operating Force | 95g |
| Mechanical Life | 1000000min |
| Contact AC Voltage | 250V |
| Microswitch Type | Subminiature |
Key Features
- The switch supports a 100mA contact current at 250V AC voltage.
- It has a single-pole double-throw contact configuration for versatile circuit switching.
- Subminiature housing made of PBT material rated to IP40 offers protection against solid objects.
- Operates reliably across a temperature range from -40°C to 125°C.
- Mechanical life of up to 1,000,000 cycles ensures durability in intermittent duty use.
- Solder terminals allow easy PCB or wiring assembly integration.
- Compact dimensions of 19.8mm length, 6.4mm width, and 10.2mm depth enable space-saving installation.
- Suitable for limit sensing, position detection, interlock sensing, and user-interface switching in industrial and electronic equipment.
Product Description
Honeywell Technologies ZM110D10A01 Micro Switch is a subminiature device featuring a pin plunger actuator with solder terminals designed for dependable electrical switching in industrial, electronic, and automation systems.
This switch supports a contact current of 100mA at an AC voltage rating of 250V, suitable for low power signal applications requiring precise control and actuation.
Constructed with PBT housing material rated IP40, it provides protection against solid objects and offers mechanical endurance up to 1,000,000 operating cycles, making it ideal for applications with intermittent duty cycles under demanding operating conditions.
Its compact dimensions (19.8mm length, 6.4mm width, 10.2mm depth) and subminiature design facilitate integration in constrained spaces within control panels, electronic instruments, and automated machinery.
The temperature operating range spans from -40°C to 125°C, allowing for use in harsh thermal environments.
The single-pole double-throw (SPDT) contact configuration provides versatile electrical switching capabilities for position sensing, limit detection, interlock mechanisms, and user interface controls.
The pin plunger actuator ensures precise linear motion detection providing reliable circuit state changes. Solder type terminals enable straightforward assembly onto printed circuit boards or wiring harnesses. Its industrial approvals and standards compliance include UL, ENEC, CE, CQC to GB 15092.1, RoHS, and REACH.
This micro switch is suitable for industrial automation, electronic control systems, HVAC equipment, manufacturing, and other commercial applications requiring robust and accurate switching devices.
The compact and durable design supports long service life and dependable performance in varied use-cases. Discover more Micro Switch options in the Electronics & Electricals category on EnvMart for your precise control and sensing solution needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The micro switch supports a contact current of 100mA.
It has a contact AC voltage rating of 250V.
This model operates reliably across a temperature range from -40°C to 125°C.
The mechanical life of this switch is rated for up to 1,000,000 cycles.
It features a pin plunger actuator for precise linear motion detection.
The housing of this switch is rated IP40, providing protection against solid objects.
The dimensions are 19.8mm in length, 6.4mm in width, and 10.2mm in depth.
It is equipped with solder terminals for easy PCB or wiring assembly integration.
The switch has a single-pole double-throw (SPDT) contact configuration.
It is suitable for limit sensing, position detection, interlock sensing, and user-interface switching in industrial and electronic equipment.
The housing is constructed from PBT material, which contributes to its durability.
It complies with UL, ENEC, CE, CQC to GB 15092.1, RoHS, and REACH standards.
