ABB Residual Current Circuit Breaker F200 Series 40A 2-Pole 300 mA Type A 1 kA 230V AC 2CSF202101R3400 - F202A-40/0.3

ABB 2CSF202101R3400 - F202A-40/0.3 Residual Current Circuit Breaker from the F200 Series delivers reliable electrical protection by detecting earth leakage currents and instantly interrupting the circuit.

This 2-pole breaker is rated for 40A current and operates at 230V AC, making it suitable for residential, commercial, and industrial electrical distribution systems.

It features a trip sensitivity of 300 mA and Type A tripping characteristics, able to detect AC and pulsating DC residual currents, which enhances safety against electrocution and fire hazards.

The breaker is designed for DIN rail mounting with screw terminals, ensuring secure and efficient installation. Its compact size with dimensions of 85mm height, 69mm depth, and 35mm width optimizes panel space usage.

The instantaneous break time and 1 kA breaking capacity provide fast and effective interruption of fault currents, protecting electrical infrastructure from damage.

Additional functionalities include a lever-type reset actuator and an auxiliary changeover contact for remote signaling and integration with monitoring systems. The device is surge-proof up to 250 A, resistant to short leakage currents to earth.

Conformance to UL 1053, RoHS, REACH, and IEC/EN 61008 standards ensures compliance with international safety and environmental regulations. Manufactured in Italy, this product offers high-quality engineering and durability for long-term operational reliability.

This ABB F200 Series Residual Current Circuit Breaker is ideal for use in electrical distribution panels in industrial, commercial, residential, and automation environments requiring robust protection against earth leakage currents.

Explore more in the Residual Current Circuit Breaker category for additional protection devices that meet diverse electrical safety needs. The breaker supports a rated AC voltage of 230V AC for residential and industrial use.

Equipped with a trip sensitivity of 300 mA for enhanced safety. Designed for DIN rail mounting with screw terminal type for secure connections. Breaking capacity is 1 kA with instantaneous break time to protect against short circuits.

Compact dimensions: 85mm height, 69mm depth, and 35mm width save panel space. Reset actuator is a lever type for easy manual resetting after tripping events. Earth leakage protection type is Type A, suitable for AC and pulsating DC fault currents.

Surge-proof up to 250 A, resistant to short leakage currents to earth. Includes a changeover auxiliary contact and supports signal contacts for enhanced monitoring. Conforms to standards UL 1053, RoHS, REACH, and IEC/EN 61008 ensuring safety and compliance.
