ABB Residual Current Circuit Breaker with Overload Protection 10A 2-Pole 10 mA Trip Sensitivity Type C DS201 2CSR255180R0104

ABB 2CSR255180R0104 Residual Current Circuit Breaker with Overload Protection is engineered for the protection of single-phase circuits against overloads and short circuits. It delivers a current rating of 10A with 2 poles and a sensitive 10 mA trip threshold to quickly respond to electrical faults.

The DS201 series breaker features a thermal magnetic tripping mechanism, which combines thermal overload and magnetic short-circuit protection to enhance operational safety and reliability. It is designed for DIN rail mounting, facilitating straightforward installation in electrical distribution boards and panels.

Installation is further simplified by screw terminals that ensure secure electrical connections. Its compact two-module width makes it suitable for modern electrical systems where space optimization is critical. The breaker supports a rated voltage of 230V AC, typical for residential and light commercial setups.

The device boasts a breaking capacity of 6kA, enabling it to handle high fault conditions effectively. Earth leakage protection of Type A is incorporated to detect sinusoidal alternating earth faults and prevent potential electrical hazards.

Constructed to meet IEC and RoHS standards, this breaker ensures compliance with global safety and environmental regulations. Its dimensions are 85mm in height, 69mm in depth, and 35mm in width, offering a compact and sturdy form factor suitable for various industrial and commercial electrical installations.

This Residual Current Circuit Breaker is ideal for industrial, commercial, and residential electrical safety applications, providing reliable protection of electrical systems. It helps in safeguarding electrical circuits from hazards such as overloads, short circuits, and earth leakage currents, thereby enhancing overall system longevity and safety.

Explore more circuit breakers and electrical safety devices in the Electronics & Electricals category at EnvMart for comprehensive solutions to your electrical protection needs. Offers robust overload and short-circuit protection with thermal magnetic tripping mechanism.

Designed for DIN rail mounting ensuring easy installation and maintenance. Equipped with screw-type terminals for secure and durable connections. Supports 230V AC rated voltage suitable for single-phase applications. Compact two-module width design fits standard system enclosures.

Features a breaking capacity of 6kA for enhanced safety. Complies with IEC and RoHS standards ensuring quality and environmental safety. Integrated earth leakage protection of Type A for sinusoidal alternating earth fault currents.
