RS PRO Pluggable Terminal Block 10-Contact 5.08 mm Pitch 1 Row 300V 8A Polyamide Housing 146-8333

Free Delivery in India | Lowest Global Shipping Charges

RS PRO Pluggable Terminal Block 10-Contact 5.08 mm Pitch 1 Row 300V 8A Polyamide Housing 146-8333

Name: RS PRO Pluggable Terminal Block 10-Contact 5.08 mm Pitch 1 Row 300V 8A Polyamide Housing 146-8333
Brand: RS PRO
SKU: 331879
Price: 20.22 USD
Availability: InStock



Category Electronic Components, Power & Connectors Brand RS PRO Condition New

Specifications

Country of Origin	China
Voltage	300V
Brand	RS PRO
Colour	Green
Orientation	Right Angle
Current	8A
Length	50.8mm
Model	146-8333
Depth	17mm
Width	15mm
Housing Material	Polyamide
Series	RS PRO
Number of Rows	1
Pitch	5.08mm
Standards/Approvals	cULus
Number of Contacts	10
Minimum Wire Size mm²	0.33mm²
Maximum Wire Size mm²	2mm²
Minimum Wire Size AWG	22AWG
Maximum Wire Size AWG	14AWG
RS PRO Pluggable Terminal Block, 10-Contact, 5.08 mm Pitch, 1 RowBrand	RS PRO

Key Features

Constructed with durable polyamide housing that is UL94-V0 flame retardant certified.
Rated for 300 volts and a current capacity of up to 8 amperes.
Supports wire sizes from 22 AWG to 14 AWG (0.33 mm² to 2 mm²) for versatile wiring options.
Features right-angle orientation and polarized mouldings to ensure secure connections.
Compact dimensions measuring 50.8 mm length, 15 mm width, and 17 mm depth.
Includes professional rising clamp terminals with captive screws for easy installation.
Guided pin alignment design facilitates accurate and secure mounting.
Complies with cULus standards ensuring quality and safety.

Product Description

RS PRO 146-8333 is a 10-contact pluggable terminal block designed for precise and reliable electrical connectivity in various industrial and commercial applications. Featuring a 5.08 mm pitch and a single-row configuration, this component is engineered to ensure robust and safe electrical connections.

The terminal block housing is manufactured from high-quality polyamide material that meets UL94-V0 flame retardant standards, offering enhanced safety against fire hazards. Rated for 300 volts and carrying a maximum current of 8 amperes, it is suitable for medium-power electrical circuits.

Wire compatibility ranges from 0.33 mm² (22 AWG) to 2 mm² (14 AWG), making it versatile for various wiring needs. The right-angle orientation with polarized mouldings ensures a secure and error-free assembly, while captive screws and rising clamp terminals facilitate straightforward wiring, reducing installation time.

Measuring 50.8 mm in length, 15 mm in width, and 17 mm in depth, it is compact enough for space-constrained PCB or panel mounting. The guided pin alignment promotes precise positioning and reliable mechanical stability during operation.

Durable polyamide housing with UL94-V0 flame retardance. Rated for 300 V and 8 A current capacity. Supports AWG wire sizes from 22 to 14. Right-angle orientation and polarized mouldings. Rising clamp terminals with captive screws for secure connections.

Guided pin alignment for accurate mounting. Complies with cULus safety standards.

This RS PRO terminal block is ideal for use in electronic components manufacturing, power connectors assembly, industrial control panels, and automation systems. Its professional-grade construction and safety approvals make it a dependable choice for demanding electrical applications.

For more options, explore RS PRO's extensive catalog of pluggable terminal blocks on EnvMart to find compatible connectors and accessories for your projects.
