RS PRO Pluggable Terminal Block, 8-Contact, 5.08 mm Pitch, 1 Row, 15A Current, 450V Voltage 144-4284

Free Delivery in India | Lowest Global Shipping Charges

RS PRO Pluggable Terminal Block, 8-Contact, 5.08 mm Pitch, 1 Row, 15A Current, 450V Voltage 144-4284

Name: RS PRO Pluggable Terminal Block, 8-Contact, 5.08 mm Pitch, 1 Row, 15A Current, 450V Voltage 144-4284
Brand: RS PRO
SKU: 331632
Price: 20.22 USD
Availability: InStock



Category Electronic Components, Power & Connectors Brand RS PRO Condition New

Specifications

Country of Origin	India
Voltage	450V
Brand	RS PRO
Colour	Green
Orientation	Straight
Current	15A
Length	40.6mm
Model	144-4284
Depth	18.1mm
Width	15.05mm
Housing Material	Nylon
Series	RS PRO
Number of Rows	1
Pitch	5.08mm
Standards/Approvals	RoHS
Number of Contacts	8
Minimum Wire Size AWG	14AWG
Maximum Wire Size AWG	28AWG
Wire Connection Method	Screw
RS PRO Pluggable Terminal Block, 8-Contact, 5.08 mm Pitch, 1 RowBrand	RS PRO

Key Features

Supports a current rating of 15A and voltage rating of 450V.
Constructed with green nylon housing offering UL94-V0 flame retardant protection.
Compatible with minimum wire size 14 AWG and maximum 28 AWG solid and stranded cables.
Features screw-type wire connection method with captive screws for secure wiring.
Designed with guided pin alignment and polarised mouldings for error-proof installation.
Suitable for industrial electronic components, power and connectors applications.
Complies with RoHS standards ensuring environmental safety.

Product Description

RS PRO 144-4284 is a high-quality pluggable terminal block featuring 8 contacts with a pitch of 5.08 mm in a single-row configuration. This component is designed for secure electrical connections in industrial, manufacturing, and electronic assembly applications.

The terminal block is constructed with a robust green nylon housing that meets UL94-V0 flame retardant standards, ensuring safety and durability in demanding environments. It supports a current rating of 15A and voltage rating up to 450V, suitable for a wide range of electrical installations.

Wire connections are made via screw terminals with captive screws, compatible with wire sizes ranging from 14 AWG to 28 AWG, supporting both solid and stranded cable types. The design provides guided pin alignment and polarised mouldings to facilitate error-free assembly and maintenance.

Its compact size, with dimensions of 40.6 mm length, 15.05 mm width, and 18.1 mm depth, makes it ideal for PCB mounting in electronic components and power connector systems. The product conforms to the RoHS directive, ensuring compliance with environmental regulations.

Supports a current rating of 15A and voltage rating of 450V. Constructed with green nylon housing featuring UL94-V0 flame retardant standard. Wire connection method is screw terminal with captive screws. Compatible with wire sizes from 14 AWG to 28 AWG solid and stranded cables.

Includes guided pin alignment and polarised mouldings for precise installation. RoHS compliant for environmental safety. Compact dimensions suitable for electronic and industrial applications.

This RS PRO terminal block is widely used in electrical control panels, power supplies, industrial automation systems, and electronic manufacturing. Its reliable performance and compliance with standards make it a preferred choice for professionals in electronics and electrical industries.
