Banner Diffuse Photoelectric Sensor, Block Sensor, 380 mm Detection Range, PNP Output, IP67 Rated SME312DQD
Specifications
| Country of Origin | United States |
|---|---|
| Brand | Banner |
| Response time | 500μs |
| Light Source | Infrared |
| Detection range | 380 mm |
| Model | SME312DQD |
| IP Rating | IP67 |
| Mount Type | Flat Mount |
| Housing Material | Reinforced Thermoplastic |
| Output type | PNP |
| Series | MINI-BEAM |
| Maximum Operating Temperature | 70°C |
| Minimum Operating Temperature | -20°C |
| Maximum Current | 150mA |
| DetectIon Type | Diffuse |
| Terminal type | 5-Pin M12 |
| Maximum dc Voltage | 30V dc |
| Standards/Approvals | IEC |
| Sensor Style | Block |
| Banner Diffuse Photoelectric Sensor, Block Sensor, 380 mm, PNP, IP67Brand | Banner |
Key Features
- Compact Mini-Beam SM312 series sensor with 18 mm threaded lens.
- Reinforced thermoplastic housing designed for flat mounting.
- Infrared light source with 500μs response time.
- PNP output with 5-pin M12 terminal connection.
- Maximum 30V DC operating voltage and 150 mA current.
- Ideal for registration mark detection and baggage handling.
- IP67 rated protection for demanding environments.
- Setup aided by multi-function LEDs.
Product Description
Banner SME312DQD Diffuse Photoelectric Sensor is part of the Mini-Beam SM312 series designed to provide reliable diffuse detection capabilities with a block sensor form factor. It features a compact design with an 18 mm threaded lens housed in robust reinforced thermoplastic material. The sensor operates with a PNP output and has a detection range of 380 mm, suitable for diverse industrial automation tasks.
The sensor supports a wide temperature range from -20°C up to 70°C and meets IEC standards ensuring dependable performance in demanding environments. Its IP67 rating guarantees protection against dust and water ingress, making it ideal for use in harsh industrial, manufacturing, and material handling conditions.
The infrared light source enables precise object detection with a fast 500 microseconds response time. The device is equipped with a 5-pin M12 terminal for reliable connections and supports both light-on and dark-on bipolar output functionalities, enhancing flexibility for automation control systems.
This sensor series is commonly utilized in applications such as registration mark detection on packaging lines, baggage handling systems at airports, and bottle conveying on production lines. The multi-function LEDs provide straightforward setup and operational status monitoring to reduce downtime and improve efficiency.
Packaged with a compatible cable (model AL-WAK4.5-2/S370GY) and mounting bracket SMB312PD, the SME312DQD sensor simplifies integration into existing automation infrastructure. Compact Mini-Beam SM312 series sensor with 18 mm threaded lens.
Reinforced thermoplastic housing designed for flat mounting. Operating temperature range: -20°C to 70°C with IEC compliance. Infrared light source with 500μs response time. PNP output with 5-pin M12 terminal connection. Maximum 30V DC operating voltage and 150 mA current.
Ideal for registration mark detection and baggage handling. IP67 rated protection for demanding environments. Setup aided by multi-function LEDs. Banner products deliver quality and reliability for electrical and automation applications. Explore more Photoelectric Sensors and automation solutions at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The detection range of the Banner SME312DQD sensor is 380 mm.
This model provides a PNP output.
The maximum operating voltage for the sensor is 30V DC.
The infrared light source has a response time of 500 microseconds.
The operating temperature range for this sensor is from -20°C to 70°C.
The sensor is housed in reinforced thermoplastic material.
The sensor is designed for flat mounting.
The sensor has an IP67 rating, indicating it is protected against dust and water ingress.
This unit uses a 5-pin M12 terminal connection for reliable connectivity.
It is commonly utilized for registration mark detection, baggage handling systems, and bottle conveying on production lines.
Yes, it supports both light-on and dark-on bipolar output functionalities, enhancing flexibility for automation control systems.
Yes, the sensor is packaged with a compatible mounting bracket (model SMB312PD).
