Banner Background Suppression Photoelectric Sensor Barrel Sensor 150 mm PNP IP67 IP68 IP69K T18-2VPFF150-Q8

Free Delivery in India | Lowest Global Shipping Charges

Banner Background Suppression Photoelectric Sensor Barrel Sensor 150 mm PNP IP67 IP68 IP69K T18-2VPFF150-Q8

Name: Banner Background Suppression Photoelectric Sensor Barrel Sensor 150 mm PNP IP67 IP68 IP69K T18-2VPFF150-Q8
Brand: Banner
SKU: 262326
Price: 188.33 USD
Availability: InStock



Category Photoelectric Sensor Brand Banner Condition New

Specifications

Country of Origin	United States
Brand	Banner
Response time	2ms
Light Source	Infrared
Detection range	150 mm
Model	T18-2VPFF150-Q8
IP Rating	IP67, IP68, IP69K
Mount Type	Flange
Housing Material	Polybutylene Terephthalate Polyester
Output type	PNP
Series	T18-2
Maximum Operating Temperature	70°C
Minimum Operating Temperature	-40°C
Maximum Current	25mA
Terminal type	4-Pin
Maximum dc Voltage	30V dc
Standards/Approvals	CE, cULus, ECOLAB
Sensor Style	Barrel
Wide operating temperature range	- 40 °C to +70 °C ( - 40 °F to +158 °F)

Key Features

High chemical resistance with epoxy encapsulated plastic housing suitable for wash-down environments.
Permanent laser etched markings ensure durability against repeated cleaning.
Powerful visible red emitter beam allows easy alignment and setup.
Wide operating temperature range from -40°C to 70°C supports demanding industrial conditions.
IP67, IP68, and IP69K ratings provide strong protection against water and dust ingress.
Fast 2 ms response time enhances automation system performance.
4-pin terminal type compatible with standard industrial wiring.
Robust design ideal for food and beverage industry and other hygienic applications.

Product Description

Banner T18-2VPFF150-Q8 is a professional-grade background suppression photoelectric sensor featuring a barrel style 18 mm threaded housing with flange mount, designed for reliable object detection up to 150 mm.

Its chemically robust epoxy encapsulated plastic housing ensures long service life and resistance to harsh wash-down and thermal shock conditions, making it well suited for food, beverage, pharmaceutical, and chemical industry automation.

The sensor uses an infrared light source with a powerful visible red emitter beam, enabling easy alignment and setup in demanding industrial environments. The permanent laser etched product marking guarantees identification durability even after repeated cleaning cycles.

The device operates with a PNP output type and 4-pin terminal interface, compatible with various control systems and PLCs. It supports a wide temperature range from -40°C to +70°C (-40°F to 158°F), with an IP67, IP68, and IP69K ingress protection rating for excellent resistance to dust, water, and high-pressure washdowns.

The sensor's 2 ms response time ensures rapid detection and contributes to efficient production automation. It complies with CE, cULus, and ECOLAB standards, assuring adherence to international quality and safety regulations.

This Banner photoelectric sensor is primarily used in industrial automation sectors including manufacturing, packaging, processing, and lab instrumentation where reliable object detection and harsh environment tolerance are critical.

High chemical resistance with epoxy encapsulation suitable for wash-down environments. Permanent laser etched marking for durability. Powerful visible red emitter beam for easy alignment. Wide operating temperature range from -40°C to +70°C.

IP67, IP68, and IP69K ingress protection ratings. Fast 2 ms response time for improved automation performance. PNP output with 4-pin terminal type. Compliant with CE, cULus, and ECOLAB approvals. Flange mount for secure installation.

Explore the full range of high-quality sensors and Photoelectric Sensor products at EnvMart for your industrial automation and control system needs.
