RS PRO 20A GPV Ceramic Cartridge Fuse, 10 x 38 mm, 600V DC, Power Characteristics, Series RS PRO 188-4484
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 600V dc |
| Diameter | 10mm |
| Brand | RS PRO |
| Body Material | Ceramic |
| Model | 188-4484 |
| Overall Length | 38mm |
| Current Rating | 20A |
| Series | RS PRO |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | IEC 60269-6 |
| Fuse Characteristics | Power |
| Fuse Size | 10 x 38 mm |
Key Features
- High breaking capacity of 10000 A at 600 V DC and 150000 A at 600 V AC ensures safety under fault conditions.
- Thermally stable ceramic body offers durability and reliable performance.
- Conductive nickel-plated copper caps improve electrical connection quality.
- Wide operating temperature range from -55°C to +125°C suits harsh environments.
- Compliance with IEC 60269-6 standard for photovoltaic protection.
- Fuse speed rated as gPV for photovoltaic array protection.
- Compact size with 10 mm diameter and 38 mm length.
- Low resistance of 0.004 Ω for efficient current flow.
Product Description
RS PRO 188-4484 is a 20 amp ceramic Cartridge Fuse designed specifically for DC electrical applications such as solar photovoltaic systems. It is constructed with a thermally stable ceramic body and features conductive nickel-plated copper end caps, allowing for excellent electrical conduction and mechanical durability.
This GPV rated fuse supports a voltage of 600 volts DC and is compliant with the IEC 60269-6 standard, ensuring it meets international requirements for photovoltaic energy systems. The fuse's breaking capacity is rated at 10000 amps at 600 volts DC, providing robust protection against overcurrent faults.
The fuse size measures 10 mm in diameter and 38 mm in overall length, making it suitable for compact fuse holders in electrical installations. It operates reliably across a wide temperature range from -55°C up to 125°C, enabling use in harsh and variable temperature environments commonly found in outdoor and renewable energy installations.
With its power characteristics and gPV fuse speed rating, RS PRO 188-4484 is well suited for the protection of solar panels, photovoltaic arrays, chargers, and control systems. Its low internal resistance of 0.004 ohms helps maintain efficient circuit performance while providing safety against electrical faults.
High breaking capacity safeguards DC circuits in photovoltaic systems. Ceramic body withstands thermal and mechanical stresses. Nickel-plated copper caps ensure reliable electrical connections. Wide operating temperature ensures durability in extreme conditions.
IEC 60269-6 compliance certifies photovoltaic system protection. Compact fuse size for easy integration in fuse holders. Low electrical resistance enhances efficiency. Widely used by renewable energy industry professionals.
This fuse is ideal for industrial, commercial, and residential solar power applications, as well as other DC circuit protection tasks requiring reliable and certified fuse elements.
Explore EnvMart's large selection of electrical fuses and circuit protection devices for dependable power system safeguarding.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The RS PRO 188-4484 ceramic cartridge fuse is rated for 600 volts DC.
This fuse has a maximum breaking capacity of 10,000 amps at 600 volts DC.
The fuse measures 10 mm in diameter and 38 mm in overall length.
The current rating of the RS PRO 188-4484 is 20 amps.
It features a thermally stable ceramic body and conductive nickel-plated copper end caps.
This model operates reliably in a wide temperature range from -55°C to 125°C.
Yes, it complies with the IEC 60269-6 standard for photovoltaic protection.
It is suitable for use in solar photovoltaic systems, chargers, and control systems requiring DC circuit protection.
The fuse speed is rated as gPV, specifically for photovoltaic array protection.
The low internal resistance of 0.004 ohms helps maintain efficient current flow in the circuit.
The RS PRO 188-4484 fuse is manufactured in Taiwan.
This fuse has power characteristics, making it suitable for various electrical applications.
