ACE Shock Absorber MC25EUMH 43 mm Body Length, 57.6 mm Overall Length, 6 mm Stroke Length, M10 x 1 Thread Size MC25EUMH
Specifications
| Country of Origin | United States |
|---|---|
| Brand | ACE |
| Length | 43mm |
| Model | MC25EUMH |
| Overall Length | 57.6mm |
| Series | MC |
| Maximum Operating Temperature | 65°C |
| Thread Size | M10 x 1 |
| Minimum Operating Temperature | 0°C |
| Stroke Length | 6mm |
| Thread Standard | UNF |
| Maximum Energy Capacity Per Cycle | 2.8Nm |
| Maximum Return Force | 6N |
| Maximum Energy Capacity Per Hour | 22600Nm |
Key Features
- Self-compensating miniature type suitable for weights from 0.3 kg to 36 kg.
- Steel body with Weartec-Plus finish and hardened stainless steel piston rod for durability.
- Operating temperature range from 0°C to 65°C for versatile applications.
- Impact velocity capabilities between 0.15 m/s and 5 m/s for effective shock absorption.
- Integral mechanical stop with a locknut and noise suppression rod end button.
- Maximum energy capacity of 22600 Nm per hour and 2.8 Nm per cycle.
- Maximum return force of 6 N ensuring consistent performance.
- Universal mounting and stop collar attachments available separately.
Product Description
ACE MC25EUMH shock absorber is a self-compensating miniature type designed to handle effective weights ranging from 0.3 kg to 36 kg. It features a robust steel body finished with Weartec-Plus for enhanced resistance to harsh environments and a hardened stainless steel piston rod that ensures long service life. The rod end includes a locknut and a hardened steel button with insert for noise suppression, making it highly reliable in industrial pneumatic applications.
This shock absorber has a body length of 43 mm, a stroke length of 6 mm, and an overall length of 57.6 mm, with a thread size of M10 x 1 UNF standard. It operates efficiently within a temperature range of 0°C to 65°C and can handle impact velocities between 0.15 m/s to 5 m/s, offering excellent energy absorption capabilities.
The maximum energy capacity per hour is 22600 Nm, with a maximum energy capacity of 2.8 Nm per cycle, and a maximum return force of 6 N. These features make the MC25EUMH model suitable for precision pneumatic shock absorption in industrial, manufacturing, laboratory, and mechanical equipment.
The integral mechanical stop is built into the front end of the unit, providing effective stroke limitation and protection. Universal mounting options and stop collar attachments can be purchased separately to accommodate various installation requirements.
Self-compensating miniature type for weights of 0.3 kg to 36 kg. Steel body with Weartec-Plus finish for harsh environments. Hardened stainless steel piston rod with noise suppression rod end. Operating temperature range of 0°C to 65°C.
Impact velocity range from 0.15 m/s to 5 m/s. Maximum energy capacity per hour of 22600 Nm. Maximum energy capacity per cycle of 2.8 Nm. Maximum return force of 6 N. Integral mechanical stop and universal mounting.
This shock absorber is manufactured to high standards in the United States, ensuring premium quality and reliability. Ideal for pneumatic cylinders and actuators in industrial, construction, manufacturing, and automation applications.
Explore EnvMart for a wide range of hydraulic and pneumatic tools, Shock Absorbers, and related products to suit various industrial needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The ACE MC25EUMH shock absorber is designed to handle effective weights ranging from 0.3 kg to 36 kg.
This model has a stroke length of 6 mm.
The overall length of the ACE MC25EUMH shock absorber is 57.6 mm.
It operates efficiently within a temperature range of 0°C to 65°C.
The thread size for this model is M10 x 1 UNF standard.
The maximum energy capacity per cycle for this unit is 2.8 Nm.
This shock absorber has a maximum return force of 6 N.
It can handle impact velocities between 0.15 m/s and 5 m/s.
The maximum energy capacity per hour is 22600 Nm.
It features a steel body finished with Weartec-Plus and a hardened stainless steel piston rod.
Yes, it has an integral mechanical stop built into the front end for effective stroke limitation.
Universal mounting options and stop collar attachments are available separately for various installation requirements.
