ABB Residual Current Device DDA 200 A Series, 40A Current Rating, 3-Pole, 300 mA Trip 2CSB204101R3400 - DDA204A-40/0,3



Category Residual Current Device Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	System Pro M Compact
Brand	ABB
Height	80mm
Model	2CSB204101R3400 - DDA204A-40/0,3
Depth	76mm
Width	105mm
Mount Type	DIN Rail
Current Rating	40A
Series	DDA 200 A
Terminal type	Screw
Breaking Capacity	0.3A
Number of Poles	3
Standards/Approvals	IEC/EN 61009, RoHS
Rated AC Voltage	415V ac
Tripping Characteristics	Type A
Reset Actuator Type	Toggle Switch
Trip Sensitivity	300mA
Break Time	Instantaneous
Earth Leakage Protection Type	Type A

Key Features

Features a type A tripping characteristic ensuring protection against AC and pulsating DC currents.
Equipped with a toggle switch for easy reset actuation.
Mountable on DIN rail for convenient installation.
Compact dimensions with width 105mm, height 80mm, and depth 76mm.
Meets IEC/EN 61009 standards and RoHS compliance.
Breaking capacity is instantaneous at 0.3 A ensuring rapid response to faults.
Suitable for electrical systems rated at 415V AC.
Supports versatile mounting with neutral conductor connector installable on right or left side.

Product Description

ABB 2CSB204101R3400 - DDA204A-40/0,3 Residual Current Device from the DDA 200 A Series is engineered for precise earth leakage detection and protection. Rated at 40A current with a 3-pole configuration, it features a trip sensitivity of 300mA and a type A tripping characteristic, making it suitable for AC and pulsating DC fault currents.

This device operates at a rated AC voltage of 415V and includes a toggle switch reset actuator for straightforward manual operation. The unit is designed for DIN rail mounting, facilitating efficient and standardized installation processes.

Manufactured to comply with IEC/EN 61009 standards and RoHS directives, this device delivers high industrial-grade reliability and environmental safety. With compact dimensions - width 105mm, height 80mm, depth 76mm - it fits seamlessly into various electrical cabinets and panels.

Breaking capacity is instantaneous at 0.3A, providing immediate disconnection upon detecting leakage currents, safeguarding users and equipment effectively. The neutral conductor connector allows installation on either right or left side, enhancing installation flexibility.

This residual current device is well-suited for commercial, industrial, and residential applications, including deployment in escalators, lifts, electrically-operated gates and barriers, machine tools, car washes, assembly lines, and conveyor belts.

Manufactured in Italy, it offers superior quality and long-term durability. Type A tripping characteristic protects against AC and pulsating DC currents. Toggle switch reset actuator for user-friendly operation. DIN rail mount type for standardized installation.

Compliance with IEC/EN 61009 and RoHS standards. Neutral conductor connector mountable on right or left side. Compact form factor with 105mm width, 80mm height, and 76mm depth. Breaking capacity instantaneous at 0.3 A. Rated for 415V AC electrical systems.

Applicable in diverse industrial and commercial environments. Explore more ABB Residual Current Devices and circuit breakers in the Electronics & Electricals category at EnvMart for comprehensive solutions.
