Schneider Electric Residual Current Circuit Breaker with Overload Protection, 25A Current Rating, 3-Pole, 30mA Trip A9DS1725

Schneider Electric A9DS1725 is a high-quality Residual Current Circuit Breaker with Overload Protection designed for residential and light commercial electrical installations. It incorporates thermal-magnetic trip unit technology which combines short circuit and overload protection, making it ideal for reliable circuit safeguarding.

This 3-pole RCBO has a current rating of 25A and operates at a rated AC voltage of 400V. Its 30mA trip sensitivity provides effective earth leakage protection, helping to prevent electrical hazards. With a breaking capacity of 4.5kA, it can safely interrupt fault currents, enhancing system safety.

The unit features a user-friendly toggle switch reset actuator and is designed for DIN rail mounting, facilitating easy integration into existing electrical panels. Its compact dimensions (93mm height, 90mm width, 73mm depth) make it space-efficient without compromising functionality.

Certified to meet RoHS and EN/IEC 60947-2 standards, this circuit breaker ensures compliance with international safety and environmental regulations. It is built for operation in ambient temperatures ranging from -5 to 60 °C, and the device supports a padlockable toggle switch to secure the breaker during maintenance operations.

The Schneider Electric Acti9 series represented by this model is recognized for its premium quality and durability with electrical endurance rating of 20,000 cycles. The breaker’s instantaneous earth-leakage protection includes a time delay enhancing the prevention of nuisance tripping. Its impulse withstand voltage rating is 4 kV, and it uses a tunnel-type terminal for secure installation.

This product is primarily used in residential, overcurrent protection, and distribution applications to ensure electrical safety and sustainability. It is manufactured in Spain, aligning with high manufacturing standards.

This residual current breaker features thermal-magnetic trip unit technology for short circuit and overload protection. It offers a rated AC voltage of 400V with a breaking capacity of 4.5kA. The device is designed with a toggle switch reset actuator and DIN rail mount type for easy installation.

Compact dimensions of 93mm height, 90mm width, and 73mm depth make it suitable for residential electrical distribution panels. Compliant with RoHS and EN/IEC 60947-2 standards ensuring safety and quality. Provides instantaneous earth leakage protection with 30mA trip sensitivity and type C tripping characteristics.

Padlockable toggle switch enhances operational safety during maintenance. Designed to operate in ambient temperatures from -5 to 60 °C with 20,000 electrical durability cycles.

For electricians, engineers, and installers involved in residential or light commercial electrical safety and automation, the Schneider Electric A9DS1725 is an essential component. It ensures circuit protection and reduces risk of electrical faults, supporting compliance with local electrical codes.
