Schneider Electric Residual Current Circuit Breaker with Overload Protection 25A Current Rating 1-Pole 30 mA Trip A9DV3625
Specifications
| Country of Origin | France |
|---|---|
| Range | Acti9 |
| Brand | Schneider Electric |
| Height | 93mm |
| Model | A9DV3625 |
| Depth | 73mm |
| Width | 36mm |
| Mount Type | DIN Rail |
| Current Rating | 25A |
| Series | Acti9 iDD40N |
| Terminal type | Tunnel |
| Breaking Capacity | 10kA |
| Number of Poles | 1 |
| Standards/Approvals | RoHS, EN/IEC 60947-2 |
| Rated AC Voltage | 400V ac |
| Tripping Characteristics | Type C |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
| Trip Sensitivity | 30mA |
| Earth Leakage Protection Type | AC |
Key Features
- Equipped with thermal magnetic trip mechanism for effective overload and short circuit protection.
- Mounts easily on DIN rail with toggle switch reset actuator for convenient operation.
- Compliance with RoHS and EN/IEC 60947-2 standards ensures high safety and quality.
- Compact dimensions of 93mm height, 73mm depth, and 36mm width fit standard electrical enclosures.
- Breaking capacity rated at 10kA for robust fault current interruption.
- Designed for use in residential and distribution electrical applications.
- Impulse withstand voltage of 4 kV for enhanced durability under transient conditions.
- Can operate in ambient temperatures ranging from -5°C to 60°C with 95% relative humidity tolerance.
Product Description
Schneider Electric A9DV3625 Residual Current Circuit Breaker with overload protection features a 25A current rating and 1-pole design, suitable for distribution and residential electrical safety applications. It incorporates a thermal magnetic trip mechanism with instantaneous earth-leakage protection and 30 mA trip sensitivity, ensuring excellent protection against overloads and short circuits.
This product supports DIN rail mounting and includes a toggle switch for reset actuation, facilitating straightforward installation and operation. Dimensions of 93mm height, 73mm depth, and 36mm width offer a compact footprint for electrical panel integration.
Compliance with RoHS and EN/IEC standards 60947-2 and 61009-2-1 guarantees product quality and safety adherence. The circuit breaker has a breaking capacity of 10kA and an impulse withstand voltage of 4 kV, supporting robust performance under electrical faults and transient events.
Designed to operate reliably in ambient temperatures from -5°C to 60°C with relative humidity tolerance up to 95%, it ensures dependable function in demanding environments. The padlockable feature adds enhanced security by preventing unauthorized access.
As part of the Schneider Electric Acti9 iDD40N series, this RCBO combines residual current and overcurrent protection in a single compact device. It is ideal for industrial, residential, and distribution circuit protection use cases, helping to safeguard electrical installations efficiently.
Equipped with thermal magnetic tripping for overload and short circuit protection. Toggle switch actuator for manual reset convenience. Compact dimensions 93 x 73 x 36 mm fit standard DIN rail enclosures. Breaking capacity rated at 10kA for fault interruption.
Complies with RoHS and EN/IEC 60947-2 standards. Impulse withstand voltage 4 kV for transient voltage resilience. Padlockable for additional safety. Suitable for residential and distribution electrical circuits. Reliable earth leakage protection with 30 mA sensitivity.
Explore more Schneider Electric circuit protection devices and related electrical components on EnvMart for your industrial and commercial projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 25A, making it suitable for various electrical applications.
The breaking capacity of this circuit breaker is rated at 10kA, providing robust fault current interruption.
It has compact dimensions of 93mm in height, 73mm in depth, and 36mm in width, which allows for easy integration into standard electrical enclosures.
It complies with RoHS and EN/IEC 60947-2 standards, ensuring adherence to safety and quality regulations.
This unit supports DIN rail mounting, facilitating straightforward installation in electrical panels.
It features a thermal magnetic tripping mechanism that provides effective overload and short circuit protection.
The trip sensitivity of this circuit breaker is 30mA, offering reliable earth leakage protection.
The impulse withstand voltage of this model is rated at 4 kV, enhancing its durability under transient conditions.
It can operate reliably in ambient temperatures ranging from -5°C to 60°C, with a relative humidity tolerance of up to 95%.
This circuit breaker is equipped with a toggle switch reset actuator for convenient manual reset operation.
This model is designed with a 1-pole configuration, suitable for single-phase applications.
It is part of the Acti9 iDD40N series, which combines residual current and overcurrent protection in a single device.
