ABB System Pro M Compact S200 Miniature Circuit Breaker, 4-Pole, 25A, Type Z Tripping 2CDS254001R0518 S204 Z 25A - 10 KA

ABB 2CDS254001R0518 S204 Z 25A - 10 KA Miniature Circuit Breaker from the System Pro M Compact S200 series offers reliable electrical protection for industrial, commercial, and residential applications. Its 4-pole configuration and 25A current rating allow for efficient multi-phase protection with precise overload control using Type Z tripping characteristics.

Designed for DIN rail mounting, this MCB supports rated voltages of 440V AC and 110V DC, making it suitable for a wide range of electrical systems including automation and distribution panels. The breaker is capable of interrupting fault currents up to 20 kA, ensuring safety and protection against electrical faults.

Complying with international standards IEC/EN 60947-2 and UL 1077, it guarantees adherence to rigorous safety and performance requirements. Its IP20 and IP40 ingress protection levels help safeguard internal components against foreign objects and partial protection against water.

The device operates within an ambient temperature range from -25°C to +55°C, with storage tolerance extending down to -40°C, thereby supporting use in varied environmental conditions. Its compact dimensions - 70mm width, 88mm height, and 69mm depth - facilitate space-saving panel designs.

Innovatively engineered with anaerobic adhesive and electromechanical tripping mechanisms, this breaker ensures precise and dependable response to overloads and short circuits. Additionally, it is designed for disassembly to support sustainability efforts.

This Miniature Circuit Breaker is ideal for use in industrial installations, building automation, electrical distribution, manufacturing plants, and other environments requiring reliable circuit protection. Its robust characteristics promote operational safety and equipment longevity.

Type Z tripping characteristic for sensitive overload protection. Rated for 440V AC and 110V DC operation. Breaking capacity of 20 kA to handle high fault currents. Complies with IEC/EN 60947-2 and UL 1077 standards. IP20 and IP40 ingress protection ratings.

Ambient operating temperature from -25°C to +55°C. Compact DIN rail mount design. Dimensions: 70 x 88 x 69 mm (WxHxD). Dual tripping mechanisms: anaerobic adhesive and electromechanic. Designed for disassembly supporting environmental sustainability.
