SICK Block Capacitive Proximity Sensor 6 mm Detection Range PNP Output 100mA 30 V dc CQF16-06EPOEP1
Specifications
| Country of Origin | Lithuania |
|---|---|
| Brand | SICK |
| Length | 34mm |
| Output signal | 100 mA, output type and function can be selected: PNP/NPN, N/O/N/C |
| Model | CQF16-06EPOEP1 |
| Depth | 8mm |
| IP Rating | IP67 |
| Width | 16mm |
| Mount Type | Non-Flush |
| Housing Material | Plastic |
| Output type | PNP |
| Series | CQF |
| Maximum Operating Temperature | 80°C |
| Minimum Operating Temperature | -25°C |
| Switching Current | 100mA |
| Body Style | Block |
| Maximum dc Voltage | 30V dc |
| Shielding | Unshielded |
| Maximum Switching Frequency | 10Hz |
| Standards/Approvals | CE, UL |
| Maximum Supply Voltage | 30V |
| Maximum Detection | 6mm |
| Food industry | Detection of food in pipes |
| Compact, rugged housing, enclosure rating | IP67, IP68, IP69K |
| Semi-conductor industry | Detection of process liquids without direct contact to the liquids |
Key Features
- Compact block style with rugged plastic housing ensures durability and IP67 protection.
- Non-flush mount type suitable for versatile installation configurations.
- Maximum switching frequency of 10 Hz appropriate for standard proximity sensing applications.
- Unshielded sensor design detects materials through container walls or direct contact.
- Operating temperature range from -25°C to 80°C suitable for diverse environments.
- Equipped with two LEDs indicating voltage supply and output signal status.
- Incorporates teach-in feature via cable for easy calibration in challenging conditions.
- Certified to CE and UL standards, including CULus certification and Ecolab approval.
Product Description
The SICK CQF16-06EPOEP1 block Capacitive Proximity Sensor features a compact and rugged plastic housing with IP67, IP68, and IP69K enclosure ratings, providing excellent protection against dust and water ingress. The sensor offers a maximum detection distance of 6 mm and supports PNP output with a 100 mA switching current at up to 30 V dc supply voltage.
This sensor's non-flush mounting style and unshielded design allow flexible installation and reliable detection of liquids or solids through container walls or by direct contact. The operating temperature range spans from -25°C to 80°C, enabling use across various industrial and laboratory environments.
Two LEDs give clear indication of voltage supply and output signal status, facilitating easy monitoring and troubleshooting. For demanding applications, the sensor supports teach-in functionality via cable, allowing fast adaptation and calibration to different conditions.
Compliance with CE, UL, and CULus standards alongside Ecolab certification ensures this sensor meets rigorous safety and quality benchmarks. Applications include liquid level detection in containers, food processing lines, semiconductor manufacturing processes, and toner level monitoring.
Supplied with a mounting bracket to simplify installation, the CQF16-06EPOEP1 sensor is engineered to deliver reliable level sensing performance even in challenging conditions involving foam, moisture, or deposits. Its compact form factor optimizes space savings, making it well suited for industrial automation and control systems.
Compact block housing with IP67, IP68, IP69K protection ratings. 6 mm maximum detection sensing distance for precise level detection. PNP output with 100 mA switching current at 30 V dc supply. Robust operation from -25°C to 80°C for varied environments.
Multiple LED indicators for status and diagnostics. Flexible teach-in programming via cable for application customization. Certified to CE and UL standards, including CULus and Ecolab approvals. Supplied mounting bracket for secure and quick installation.
Applications in semiconductor, food, and general industrial liquid level detection. Explore more sensors and automation control solutions at EnvMart for your industrial and laboratory needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum detection range of this model is 6 mm.
It provides a PNP output with a maximum switching current of 100 mA.
The operating temperature range spans from -25°C to 80°C, making it suitable for various environments.
The sensor has a length of 34 mm, a width of 16 mm, and a depth of 8 mm.
This sensor has an IP67 rating, providing protection against dust and water ingress.
The maximum supply voltage is 30 V dc.
The teach-in feature allows for easy calibration via cable, enabling adaptation to different application conditions.
It can detect both liquids and solids, either through container walls or by direct contact.
Applications include liquid level detection in the food industry, semiconductor manufacturing, and toner level monitoring.
It is certified to CE and UL standards, including CULus certification and Ecolab approval.
This model features a non-flush mounting style, allowing for versatile installation configurations.
