Myrra Through Hole 2 Output PCB Transformer 15 V ac EN 61558-2-6 1 VA 44058

Free Delivery in India | Lowest Global Shipping Charges

Myrra Through Hole 2 Output PCB Transformer 15 V ac EN 61558-2-6 1 VA 44058

Name: Myrra Through Hole 2 Output PCB Transformer 15 V ac EN 61558-2-6 1 VA 44058
Brand: Myrra
SKU: 302518
Price: 7.2 USD
Availability: InStock



Category PCB Transformer Brand Myrra Condition New

Specifications

Country of Origin	France
Brand	Myrra
Length	32.6mm
Model	44058
Depth	22.2mm
Gross Weight	70g
Width	27.6mm
Mount Type	Through Hole
Maximum Operating Temperature	70°C
Number of outputs	2
Standards/Approvals	EN 61558-2-6
Isolation Voltage	4kV
Primary Voltage	230 V ac
Secondary Voltage	15 V ac
Minimum Operating Frequency	50Hz
Maximum Operating Frequency	60Hz
Block 15 V ac 2 Output Through Hole PCB Transformer, VDE, UL 0.5 VABrand	Block
Transformer,encapsulated,PCB mount,1.0VA,2x15VBrand	Block

Key Features

This transformer provides a secondary voltage of 15 V ac and primary voltage of 230 V ac.
It features a power rating of 1 VA and is suitable for PCB mounting through-hole applications.
Constructed with an EI 30 type core, it includes encapsulated construction ensuring durability and safety.
Operating frequency ranges between 50 Hz and 60 Hz for compatibility with various AC mains supplies.
Isolation voltage withstands up to 4 kV, ensuring safety and compliance with safety standards.
Maximum operating temperature is 70°C, suited for typical electronic component environments.
Compact dimensions are 32.6 mm length, 27.6 mm width, and 22.2 mm depth, facilitating space-efficient PCB integrations.
The unit weighs approximately 70 g, making it a lightweight and easy-to-handle component.

Product Description

Myrra 44058 Through Hole PCB Transformer is a professional safety transformer designed for reliable and safe operation on printed circuit boards. Featuring a secondary voltage of 15 V ac and a power rating of 1 VA, this unit is an ideal choice for power supply and transformer applications adhering to EN 61558-2-6 standards.

This transformer is built with an EI 30 core type and encapsulated construction, featuring vacuum-filled resin to ensure materials withstand aging and provide enhanced safety. It operates efficiently within a frequency range of 50 Hz to 60 Hz and can tolerate a maximum operating temperature of 70°C, suitable for various electronic environments.

The isolation voltage rating of 4 kV offers robust protection, while its compact dimensions of 32.6 mm (length) x 27.6 mm (width) x 22.2 mm (depth) and a weight of 70 g make it suitable for space-restricted PCB installations. The device mounts through-hole style, suited for integration on printed circuit boards with standard European grid compatibility.

Manufactured in France, this transformer complies with UL, VDE, and IEC safety and quality standards, specifically UL 94-V0, VDE 0551, and IEC 742, which confirms its high reliability and safety for industrial, electronic, and laboratory use.

This transformer provides dual 15 V ac outputs on a through-hole PCB mount. Vacuum-filled resin encapsulation enhances durability and aging resistance. Professional safety insulation rated above 4000 V for high voltage protection.

Compliance with EN 61558-2-6, UL, VDE, and IEC safety standards. Compact size to fit constrained PCB areas, measuring 32.6 x 27.6 x 22.2 mm. Lightweight design at 70 grams facilitates easy handling during assembly. Designed for use in industrial, electronic, and laboratory transformer applications.

Operating temperature up to 70°C for stable performance under standard conditions. Installation requires fixing screws, which are not provided, allowing mounting flexibility. Explore more high-quality transformers in the Electronics & Electricals category at EnvMart for trusted product performance and extensive application support.
