IXYS High Voltage 2200 V 270 A 3-Pin Y1-CU Diode Panel Mount MDD255-22N1
Specifications
| Country of Origin | India |
|---|---|
| Brand | IXYS |
| Height | 49mm |
| Length | 115mm |
| Model | MDD255-22N1 |
| Width | 50mm |
| Mount Type | Panel |
| Series | MDD255 |
| Maximum Operating Temperature | 150°C |
| Package Type | Y1-CU |
| Minimum Operating Temperature | -40°C |
| Pin Count | 3 |
| Maximum Continuous Forward Current If | 270A |
| Peak Reverse Repetitive Voltage Vrrm | 2200V |
| Diode Configuration | Series |
| Rectifier Type | High Voltage |
| Peak Reverse Current Ir | 30mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 10.6kA |
| Maximum Forward Voltage Vf | 1.4V |
| IXYS 1600 V 270 A Diode General Purpose 3-Pin Y1-CU MDD255-16N1Brand | IXYS |
Key Features
- Constructed for panel mounting with a 3-pin Y1-CU package type.
- Features a series diode configuration with a peak reverse repetitive voltage of 2200 V.
- Supports peak non-repetitive forward surge current up to 10.6 kA.
- Maximum forward voltage is 1.4 V, allowing efficient conduction.
- Operates reliably within a temperature range of -40°C to 150°C.
- Peak reverse current is rated at 30 mA ensuring low leakage.
- No automotive certification but UL recognized component quality assurance.
- Ideal for use in industrial power rectification and high voltage applications.
Product Description
IXYS MDD255-22N1 is a robust high voltage diode designed for industrial and power electronics applications. It features a 3-pin Y1-CU package and supports panel mounting, suitable for integration into diverse electrical assemblies.
With a peak reverse repetitive voltage of 2200 V and a maximum continuous forward current of 270 A, this diode ensures reliable performance in demanding environments. The series diode configuration and a maximum forward voltage of 1.4 V contribute to efficient power rectification.
Operating temperature ranges from -40°C to 150°C, the device withstands harsh conditions typical in industrial setups. Its compact size with dimensions of 115 mm in length, 50 mm in width, and 49 mm in height allows flexible mounting options without compromising on performance.
The diode also supports a peak non-repetitive forward surge current of 10.6 kA, enabling it to handle transient surges effectively. Leakage current is minimized with a peak reverse current of 30 mA, enhancing energy efficiency.
IXYS MDD255-22N1 is UL recognized, assuring compliance with industrial safety standards. It is suited for power rectification, high voltage switching, and industrial power supply circuits in sectors like manufacturing, automation, and energy.
Constructed for panel mounting with a 3-pin Y1-CU package type. Series diode configuration with 2200 V peak reverse voltage. Maximum continuous forward current rating of 270 A. Peak non-repetitive forward surge current of 10.6 kA supported.
Operational temperature range from -40°C to 150°C. Compact dimensions: 115 mm (L) x 50 mm (W) x 49 mm (H). Peak reverse current limited to 30 mA. UL recognized for quality assurance. Ideal for power rectification and industrial high voltage applications.
This diode module offers dependable performance for electrical engineering, industrial manufacturing, HVAC systems, and energy management applications. Browse more semiconductor components and power rectifiers at EnvMart for comprehensive solutions.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The peak reverse repetitive voltage of this diode is 2200 V.
It has a maximum continuous forward current rating of 270 A.
The diode supports a peak non-repetitive forward surge current of 10.6 kA.
The dimensions are 115 mm in length, 50 mm in width, and 49 mm in height.
It operates reliably within a temperature range of -40°C to 150°C.
The maximum forward voltage is 1.4 V.
This model is designed for panel mounting with a 3-pin Y1-CU package type.
The peak reverse current is rated at 30 mA, ensuring low leakage.
Yes, it is UL recognized, assuring compliance with industrial safety standards.
It is ideal for power rectification and high voltage applications in industrial settings.
The MDD255-22N1 features a series diode configuration.
The country of origin is India.
