Vishay 100 V 20 A Schottky Diode Surface Mount 8-Pin FlatPAK 5 x 6 V20KM120-M3/H
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 1.09mm |
| Length | 6.35mm |
| Model | V20KM120-M3/H |
| Width | 5.3mm |
| Mount Type | Surface |
| Maximum Operating Temperature | 165°C |
| Package Type | FlatPAK 5 x 6 |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS |
| Pin Count | 8 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 20A |
| Peak Reverse Repetitive Voltage Vrrm | 100V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 30mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 220A |
| Maximum Forward Voltage Vf | 0.87V |
Key Features
- Employs Trench MOS Barrier Schottky technology for ultra low forward voltage.
- Maximum forward voltage of 0.87 V to minimize power loss and improve efficiency.
- Operates over a wide temperature range from -40°C to 165°C.
- High surge current rating of 220 A peak non-repetitive for robust performance.
- Complies with RoHS and automotive standard AEC-Q101 for quality assurance.
- Suitable for low voltage, high frequency inverters, freewheeling, DC/DC converters, and polarity protection.
Product Description
The Vishay V20KM120-M3/H is a high current density Schottky diode designed for surface mount applications in automotive, industrial, and power electronic devices. It utilizes advanced Trench MOS Barrier Schottky technology to deliver an ultra-low forward voltage drop of 0.45 V at 5 A, thereby reducing power losses and enabling higher efficiency operation in circuits.
This diode supports a maximum continuous forward current of 20 A and a peak reverse repetitive voltage of 100 V, making it ideal for use in low voltage, high frequency inverters, freewheeling applications, and DC/DC converter modules. The device’s peak non-repetitive forward surge current can reach 220 A, providing robustness against transient currents.
Measuring just 6.35 mm in length, 5.3 mm in width, and 1.09 mm in height, its compact FlatPAK 5 x 6 surface mount package with 8 pins facilitates efficient PCB layout and thermal management. The component meets industry standards including RoHS compliance and the automotive AEC-Q101 certification, ensuring suitability for automotive electronics and reliable long-term usage.
Operating temperature ranges from a minimum of -40°C up to 165°C maximum, enabling performance in harsh environments. Its low power dissipation characteristics make it an excellent choice for applications demanding lightweight and high-efficiency rectification solutions.
Employs Trench MOS Barrier Schottky technology for ultra low forward voltage. Maximum forward voltage of 0.87 V minimizes power losses and improves efficiency. Supports a high peak non-repetitive surge current of 220 A for transient robustness.
Compact 8-pin FlatPAK 5 x 6 surface mount design optimizes PCB space and thermal handling. Meets RoHS and AEC-Q101 automotive standards for compliance and reliability. Wide operating temperature range from -40°C to 165°C for harsh industrial environments.
Ideal for use in low voltage high frequency inverters, freewheeling, DC/DC converters, and polarity protection circuits.
This Vishay Schottky diode is suitable for industrial, automotive, laboratory, and power electronics manufacturing applications requiring efficient rectification and polarity protection. Explore more Vishay semiconductor components and accessories in the EnvMart electronics category for your project needs.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for the Vishay V20KM120-M3/H Schottky diode is 20 A.
This model has a peak reverse repetitive voltage rating of 100 V.
The maximum forward voltage of the V20KM120-M3/H is 0.87 V.
The diode comes in a FlatPAK 5 x 6 package, measuring 6.35 mm in length, 5.3 mm in width, and 1.09 mm in height.
The peak non-repetitive forward surge current rating for this diode is 220 A.
It operates over a wide temperature range from -40°C to 165°C.
Yes, it complies with RoHS and the automotive standard AEC-Q101.
The diode configuration for the V20KM120-M3/H is single.
The peak reverse current rating for this diode is 30 mA.
This diode is suitable for low voltage, high frequency inverters, freewheeling applications, and DC/DC converters.
The V20KM120-M3/H supports surface mounting.
It employs Trench MOS Barrier Schottky technology for ultra-low forward voltage.
