Vishay 170 V 20 A Schottky Diode Single Rectifier Surface Mount 8-Pin FlatPAK 5 x 6 V20K170-M3/H
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 1.09mm |
| Length | 6.35mm |
| Model | V20K170-M3/H |
| Width | 5.3mm |
| Mount Type | Surface |
| Maximum Operating Temperature | 165°C |
| Package Type | FlatPAK 5 x 6 |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS |
| Pin Count | 8 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 20A |
| Peak Reverse Repetitive Voltage Vrrm | 170V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 6mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 220A |
| Maximum Forward Voltage Vf | 1.02V |
Key Features
- Maximum continuous forward current of 20 A ensures high current handling capability.
- Peak reverse repetitive voltage rating of 170 V supports robust operation.
- Low maximum forward voltage of 1.02 V provides efficient power conversion.
- Compact FlatPAK 5 x 6 package with 8-pin configuration for surface mount applications.
- Wide operating temperature range from -40°C to 165°C for industrial environments.
- Trench MOS Barrier Schottky (TMBS) technology ensures low forward voltage drop and high efficiency.
- Compliant with RoHS standards and automotive-grade AEC-Q101 certification.
- Peak non-repetitive forward surge current of 220 A enables handling transient surges.
Product Description
Vishay V20K170-M3/H is a high current density Schottky barrier diode featuring Trench MOS Barrier Schottky technology for ultra low forward voltage drop of 0.57 V at 5 A forward current. This single rectifier diode is surface mount mounted in an 8-pin FlatPAK 5 x 6 package, measuring 6.35 mm in length, 5.3 mm in width, and 1.09 mm in height. It supports a maximum continuous forward current of 20 A and peak reverse repetitive voltage of 170 V, making it suitable for applications requiring efficient low voltage power rectification.
Built for industrial, automotive, and power electronics use, this diode offers low power losses and high efficiency, ideal for low voltage high frequency inverters, freewheeling diodes, DC/DC converters, and polarity protection circuits. The device operates reliably over a wide temperature range of -40°C to 165°C and meets automotive standard AEC-Q101 as well as RoHS compliance.
This Schottky diode supports a peak non-repetitive forward surge current of 220 A, enabling it to withstand transient overload conditions. The product's low forward voltage drop minimizes heat dissipation, enhancing system reliability and reducing cooling requirements.
Maximum continuous forward current of 20 A ensures high current handling capability. Peak reverse repetitive voltage rating of 170 V supports robust operation. Low maximum forward voltage of 1.02 V provides efficient power conversion.
Compact FlatPAK 5 x 6 package with 8-pin configuration for surface mount applications. Wide operating temperature range from -40°C to 165°C for industrial environments. Trench MOS Barrier Schottky (TMBS) technology ensures low forward voltage drop and high efficiency.
Compliant with RoHS standards and automotive-grade AEC-Q101 certification. Peak non-repetitive forward surge current of 220 A enables handling transient surges.
The Vishay V20K170-M3/H diode is a reliable and efficient power solution for industrial and automotive power electronics, providing superior performance in demanding environments. Explore additional Vishay semiconductor components for enhanced design flexibility on EnvMart.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of the Vishay V20K170-M3/H Schottky diode is 20 A.
This model has a peak reverse repetitive voltage rating of 170 V.
The forward voltage drop at 5 A for this diode is 0.57 V.
It comes in a FlatPAK 5 x 6 package, measuring 6.35 mm in length, 5.3 mm in width, and 1.09 mm in height.
The operating temperature range for this diode is from -40°C to 165°C.
This diode complies with the automotive standard AEC-Q101.
The peak non-repetitive forward surge current rating is 220 A.
The maximum forward voltage for this Schottky diode is 1.02 V.
The pin count for this model is 8 pins.
Yes, this diode is compliant with RoHS standards.
The Vishay V20K170-M3/H is a single rectifier Schottky diode.
This diode is designed for surface mounting.
