Vishay 600 V 30 A General Purpose Rectifier & Schottky Diode TO-247AD 2L VS-E5TX1506THN3
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 29.27mm |
| Length | 10.51mm |
| Model | VS-E5TX1506THN3 |
| Mount Type | Through Hole |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-247AD 2L |
| Minimum Operating Temperature | -55°C |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 30A |
| Peak Reverse Repetitive Voltage Vrrm | 600V |
| Diode Configuration | Single |
| Rectifier Type | General Purpose |
| Peak Reverse Current Ir | 500μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 185A |
| Maximum Forward Voltage Vf | 1.3V |
Key Features
- Features AEC-Q101 automotive standard qualification ensuring high reliability.
- Maximum operating junction temperature up to 175°C for harsh environments.
- Low forward voltage drop of 1.3 V reduces conduction losses.
- Peak non-repetitive forward surge current of 185 A for transient tolerance.
- Optimized for high-speed switching with low Qrr losses for efficient power conversion.
- Minimum operating temperature down to -55°C suits diverse industrial applications.
Product Description
Vishay VS-E5TX1506THN3 is a high-performance General Purpose Rectifier & Schottky Diode designed to meet demanding industrial and automotive applications with a maximum continuous forward current of 30 A and peak reverse voltage of 600 V. Its TO-247AD 2L package ensures excellent heat dissipation and mechanical robustness suitable for through-hole mounting on PCBs.
This diode features optimized ultra-fast switching capabilities with a low forward voltage drop of 1.3 V, which minimizes conduction losses and improves overall energy efficiency in power management circuits. It is especially well-suited for soft switching and resonant converters in electric vehicle (EV) and hybrid electric vehicle (HEV) battery chargers, providing improved high-speed LLC output rectification stages. The device complies with AEC-Q101 automotive standards and withstands a wide temperature range from -55°C to 175°C junction temperature, ensuring reliability in varied environmental conditions.
The diode’s peak non-repetitive forward surge current rating of 185 A offers robustness against transient surges. Additionally, it is single diode configured with low peak reverse current of 500 μA, reducing leakage and improving device efficiency. The compact size with a length of 10.51 mm and height of 29.27 mm allows for flexible layout designs in industrial electronics, power supply units, and general semiconductor applications.
Mount Type: Through Hole for secure PCB assembly. Package Type: TO-247AD 2L for enhanced cooling and durability. Maximum Continuous Forward Current: 30 A supports heavy current loads. Peak Reverse Voltage: 600 V for high voltage blocking capability.
AEC-Q101 Automotive Standard Qualified for automotive-grade reliability. Operating Temperature Range: -55°C to 175°C supports harsh environments. Low Forward Voltage Drop: 1.3 V enhances power efficiency. Peak Non-Repetitive Forward Surge Current: 185 A ensures surge tolerance.
Compact Dimensions allow easy integration in various electronics.
This Vishay diode is widely used in industrial power rectification, EV/HEV charging systems, power supplies, soft switched converters, and resonant converter topologies. Its combination of low conduction and switching losses make it a preferred choice for high speed and high frequency power electronics applications in manufacturing, automotive, and energy sectors.
For comprehensive product data, designspark compatibility, and schematics, users can consult Vishay's technical documentation. Explore more semiconductor solutions and electronic components with EnvMart's selection.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for this model is 30 A.
This diode has a peak reverse voltage rating of 600 V.
The operating temperature range for this diode is from -55°C to 175°C.
It features a low forward voltage drop of 1.3 V, which helps reduce conduction losses.
The package type is TO-247AD 2L, designed for through-hole mounting.
The peak non-repetitive forward surge current rating is 185 A, providing robustness against transient surges.
This model is configured as a single diode.
It complies with the AEC-Q101 automotive standard, ensuring high reliability for automotive applications.
The dimensions are 10.51 mm in length and 29.27 mm in height.
This diode is suitable for industrial power rectification, EV/HEV charging systems, and soft switched converters.
The peak reverse current is rated at 500 μA, which helps reduce leakage.
It is optimized for high-speed switching with low Qrr losses, enhancing efficiency in power management circuits.
