Honeywell Technologies Gauge Pressure Sensor Through Hole DIP Package 8 Pin 3.3V-5V SSCDANV015PGAA5
Specifications
| Country of Origin | India |
|---|---|
| Accuracy | ±0.25 % |
| Brand | Honeywell |
| Maximum Operating Pressure | 15 psi |
| Height | 13.75mm |
| Length | 10mm |
| Model | SSCDANV015PGAA5 |
| Sensor Type | Absolute Pressure Sensor |
| Mount Type | Through Hole |
| Series | SSC |
| Maximum Operating Temperature | 85°C |
| Port Type | Single Axial Barbed |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| Pin Count | 8 |
| Maximum Supply Voltage | 5V |
| Minimum Supply Voltage | 3.3V |
| Minimum Operating Pressure | 0psi |
| Maximum Overload Pressure | 30psi |
Key Features
- Provides an accuracy of ±0.25% for reliable sensing applications.
- Operates within supply voltage range from 3.3V to 5V for versatile interfacing.
- Maximum operating pressure is 15 psi with an overload tolerance up to 30 psi.
- Designed with a single axial barbed port for easy pressure connection.
- Supports operating temperatures from -40°C up to 85°C for robust environments.
- Features an 8-pin DIP package with through-hole mount for straightforward PCB integration.
- Compact dimensions with 10mm length and 13.75mm height for space-efficient design.
- Part of Honeywell SSC series with proven long-term stability and RoHS compliance.
Product Description
Honeywell SSCDANV015PGAA5 is a high-accuracy gauge pressure sensor designed for precision measurement in electronic and industrial applications. Featuring a piezoresistive silicon ceramic sensing element in an 8-pin DIP through-hole package, it provides a ratiometric analog output optimized for easy integration in sensor IC assemblies.
The sensor operates reliably over a broad voltage supply range of 3.3V to 5V and withstands maximum pressure conditions of 15 psi, with an overload capacity of 30 psi. Its operating temperature range of -40°C to 85°C ensures stable performance in demanding environments including automotive, HVAC, medical instrumentation, and laboratory devices.
With ±0.25% accuracy, it supports precise pressure measurement and control. The sensor’s single axial barbed port provides straightforward pneumatic connection, and its compact size (10mm length, 13.75mm height) facilitates compact device designs.
Part of the SSC series, this Honeywell sensor meets RoHS compliance and offers industry-leading long-term stability. It is ideal for use in semiconductor equipment, process control, fluid measurement, and other industrial pressure sensing applications.
Provides an accuracy of ±0.25% for reliable sensing applications. Operates within supply voltage range from 3.3V to 5V for versatile interfacing. Maximum operating pressure is 15 psi with an overload tolerance up to 30 psi.
Designed with a single axial barbed port for easy pressure connection. Supports operating temperatures from -40°C up to 85°C for robust environments. Features an 8-pin DIP package with through-hole mount for straightforward PCB integration.
Compact dimensions with 10mm length and 13.75mm height for space-efficient design. Part of Honeywell SSC series with proven long-term stability and RoHS compliance. This Honeywell Pressure Sensor is suitable for industrial, laboratory, HVAC, automotive, and manufacturing use cases where precise and stable pressure sensing is required.
Explore the range of Honeywell pressure sensing products on EnvMart for advanced sensor solutions optimized for diverse applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Honeywell SSCDANV015PGAA5 gauge pressure sensor provides an accuracy of ±0.25%.
This model has a maximum operating pressure of 15 psi and can tolerate an overload pressure of up to 30 psi.
The sensor operates within a supply voltage range from 3.3V to 5V, allowing for versatile interfacing.
The sensor has compact dimensions of 10mm in length and 13.75mm in height.
It supports operating temperatures from -40°C up to 85°C, making it suitable for robust environments.
This unit is designed with a single axial barbed port for easy pressure connection.
The Honeywell SSCDANV015PGAA5 features a through-hole mount in an 8-pin DIP package for straightforward PCB integration.
This model is suitable for applications in automotive, HVAC, medical instrumentation, and laboratory devices.
This sensor is classified as an absolute pressure sensor.
The pressure sensor features an 8-pin configuration.
Yes, the Honeywell SSCDANV015PGAA5 meets RoHS compliance standards.
This model is part of the Honeywell SSC series, known for its long-term stability.
