SICK Block Capacitive Proximity Sensor CQF16-06EPSEP1 6 mm Detection Range PNP Output 100mA 30 V DC

SICK CQF16-06EPSEP1 Block Capacitive Proximity Sensor is engineered for precise and reliable liquid level detection through container walls or direct contact in industrial environments. It features a compact plastic block housing designed for non-flush mounting and provides a robust IP67 protection rating with extensions to IP68 and IP69K, making it suitable for harsh and wet conditions.

The sensor's maximum detection range is 6 mm, optimized for sensing water-based liquids with conductivity up to 50 µS/cm. It supports a PNP output type with a maximum switching current of 100 mA at 30 V DC and has a maximum switching frequency of 10 Hz, ensuring timely and accurate level measurements.

Dual indicator LEDs facilitate monitoring of power supply and output signals, streamlining installation and diagnostics. The CQF16-06EPSEP1 model allows quick commissioning with plug-and-play functionality and offers a teach-in mode through its cable for adaptation to demanding applications involving foam, moisture, or deposits.

Common industrial applications include level detection through container walls in semiconductor processes, food industry liquid detection in pipes, condensate water measurement in freezers, and adhesive container level measurement. The sensor also supports toner fill level monitoring, highlighting its versatility.

This device complies with CE and UL standards and carries rugged certifications such as CULus and Ecolab. With a temperature operating range from -25°C to 80°C and manufactured in Lithuania, it is suitable for a wide range of industrial, laboratory, and food processing environments.

Compact plastic block housing for non-flush mounting with IP67/68/69K ratings. Detects water-based liquids up to 6 mm sensing distance with conductivity tolerance. PNP output signal with selectable output function and max current of 100 mA at 30 V DC.

Dual LED indicators for power and output status enable easy diagnostics. Flexible installation options with supplied mounting bracket and teach-in capability. Highly reliable level detection compensating for foam, moisture, and deposits.

Compliant with CE, UL standards, and certifications for semiconductor and food industry. Wide operating temperature range (-25°C to 80°C) suitable for diverse environments. Applications in semiconductor, food processing, freezer condensate, adhesive containers, and toner fill level.

Manufactured in Lithuania ensuring quality and industrial reliability. Explore more reliable sensors and capacitive proximity devices in the Electronics & Electricals category on EnvMart.
