Schneider Electric Residual Current Circuit Breaker with Overload Protection 16A 1-Pole 300mA Trip A9DS5616

Schneider Electric A9DS5616 Residual Current Circuit Breaker with Overload Protection is a state-of-the-art 16A, 1-pole circuit protection device designed for residential and distribution use. This device combines residual current protection with overload current protection through advanced thermal-magnetic trip unit technology, ensuring superior safety against short circuits and overloads.

The breaker features a toggle switch actuator for straightforward ON/OFF control and provides clear trip indication for quick fault diagnosis. It is designed to be mounted on DIN rails with tunnel terminal connections facilitating secure and easy wiring installations.

Compliant with international standards such as EN/IEC 60947-2 and RoHS, this circuit breaker meets rigorous quality and safety benchmarks. Its 4.5 kA breaking capacity ensures high fault current interruption capability, making it suitable for a range of residential and light commercial electrical distribution applications.

With physical dimensions of 85mm height, 73mm depth, and 36mm width, it occupies minimal space in electrical panels, facilitating compact setups. The device operates reliably across ambient temperatures from -5 to 60 °C and offers a padlockable reset actuator for enhanced operational security.

This product is manufactured in France and carries the Schneider Electric Green premium class, underscoring its environmental compliance and sustainable production. It is ideally suited for applications requiring sensitive earth-leakage protection and overload current protection in an integrated solution.

Features thermal-magnetic trip unit technology with instantaneous earth-leakage protection time delay. Toggle control for ON/OFF function with clear trip indication. Compact DIN rail mounting with tunnel type terminals. Complies with EN/IEC 60947-2 and RoHS standards.

Breaking capacity up to 4.5 kA for superior fault interruption. Designed for residential and distribution circuit applications. Ambient temperature operation range from -5 to 60 °C. Padlockable reset actuator for safety and security.

Manufactured in France under Schneider Green premium classification.
