Schneider Electric Residual Current Circuit Breaker with Overload Protection 40A Current Rating 1-Pole 30 mA Trip A9DV3640
Specifications
| Country of Origin | France |
|---|---|
| Range | Acti9 |
| Brand | Schneider Electric |
| Height | 93mm |
| Model | A9DV3640 |
| Depth | 73mm |
| Width | 36mm |
| Mount Type | DIN Rail |
| Current Rating | 40A |
| Series | Acti9 iDD40N |
| Terminal type | Tunnel |
| Breaking Capacity | 10kA |
| Number of Poles | 1 |
| Standards/Approvals | EN/IEC 60947-2, RoHS |
| Rated AC Voltage | 400V ac |
| Tripping Characteristics | Type C |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
| Trip Sensitivity | 30mA |
| Earth Leakage Protection Type | AC |
Key Features
- It features a thermal-magnetic tripping mechanism to protect against overload and short circuits.
- Mounts on DIN rail and uses a toggle switch for reset actuator.
- Supports rated AC voltage of 400V with breaking capacity of 10kA.
- Has tunnel type terminals and AC earth leakage protection type.
- Produced under Schneider Electric's Acti9 iDD40N series complying with EN/IEC 60947-2 and RoHS standards.
- Designed for applications in overcurrent protection, residential and distribution environments.
- Operates reliably in ambient temperatures from -5°C to 60°C with 95% relative humidity tolerance.
Product Description
Schneider Electric A9DV3640 Residual Current Circuit Breaker with Overload Protection is a 40A rated device featuring a 1-pole configuration and a trip sensitivity of 30 mA. It is engineered with thermal-magnetic trip unit technology, providing instantaneous earth-leakage protection with an incorporated time delay to enhance safety.
This model belongs to the Acti9 iDD40N series and complies with international standards EN/IEC 60947-2 and RoHS, ensuring high reliability and environmental compliance. The breaker includes a toggle switch reset actuator and features a tunnel terminal type with a DIN rail mounting for easy installation.
The breaker offers a breaking capacity of 10kA and supports a rated AC voltage of 400V, suitable for residential and distribution circuit protection. Its earth leakage protection type is AC, optimized for instantaneous detection and interruption of fault currents.
With compact dimensions of 93mm height, 36mm width, and 73mm depth, the product is designed to fit into standard electrical panels. Its thermal-magnetic tripping mechanism protects efficiently against overloads and short circuits, enhancing circuit durability and safety.
Designed to operate in ambient air temperatures ranging from -5°C to 60°C and relative humidity up to 95% at 55°C, this circuit breaker is robust and reliable for varied environments. The device is padlockable for extra protection and classified under Schneider Green premium class to promote sustainability.
Thermal-magnetic trip unit technology provides reliable overload protection. Toggle switch control with ON/OFF and trip indicator for easy operation. Mounts easily on DIN rail for secure electrical panel installation. Complies with EN/IEC 60947-2 and RoHS standards ensuring safety and environmental friendliness.
Breaking capacity rated at 10kA supports high fault current interruption. Compact size and padlockable feature for added security. Suitable for residential and distribution applications requiring overcurrent protection.
Ideal for use in industrial, residential, and commercial electrical panels, this Schneider Electric Residual Current Circuit Breaker effectively combines protection and durability. For more options and industrial electrical protection devices, explore the full range available at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 40A.
The breaking capacity of this circuit breaker is 10kA.
It mounts on a DIN rail, allowing for secure installation in electrical panels.
The rated AC voltage supported by this circuit breaker is 400V.
This circuit breaker has dimensions of 93mm in height, 36mm in width, and 73mm in depth.
It features a thermal-magnetic tripping mechanism for overload and short circuit protection.
The trip sensitivity of this model is 30mA.
This circuit breaker complies with EN/IEC 60947-2 and RoHS standards.
It provides AC earth leakage protection, optimized for instantaneous detection of fault currents.
It operates reliably in ambient temperatures ranging from -5°C to 60°C.
The reset actuator is a toggle switch, allowing for easy ON/OFF control and trip indication.
Yes, it is designed for overcurrent protection in residential and distribution environments.
