Schneider Electric Residual Current Circuit Breaker with Overload Protection 10A 230V AC 1-Pole 300mA Trip A9DS5610

Schneider Electric A9DS5610 Residual Current Circuit Breaker with Overload Protection is a high-performance circuit protection device designed for residential and distribution panels. With a 10A current rating, 1-pole configuration, and 300mA earth leakage trip sensitivity, it provides reliable protection against overload currents, short circuits, and earth leakage faults. The thermal-magnetic trip unit technology allows for fast and accurate tripping under fault conditions while ensuring normal operation during transient events.

The breaker features a robust toggle switch reset actuator and an easy clip-on DIN rail mounting system, facilitating straightforward installation and maintenance. It has a rated AC voltage of 230V and a breaking capacity of 4.5kA, suitable for typical household and light commercial electrical systems. Its compact dimensions of 85mm height, 73mm depth, and 36mm width allow it to fit seamlessly within standard distribution boards.

Manufactured in France, this Acti9 series device conforms to international safety standards including EN/IEC 60947-2 and the RoHS directive, ensuring compliance with environmental and electrical safety requirements. The earth leakage protection type is AC, and the tripping characteristic is Type C, suitable for general-purpose circuit protection.

The device supports an ambient operation temperature range from -5 to 60 degrees Celsius and offers a high electrical durability rating of 20,000 cycles. Its padlockable design increases safety by preventing unauthorized operation. This Schneider Electric Residual Current Circuit Breaker is an ideal choice for protecting residential and commercial electrical installations from hazardous faults and overloads, contributing to safety and operational reliability.

The device incorporates thermal-magnetic tripping mechanism for effective overload and short circuit protection. It mounts easily on DIN rails with toggle switch reset actuator for simple operation. The breaker has a breaking capacity of 4.5kA, supporting 230V AC rated voltage applications.

Compact dimensions of 85mm height, 73mm depth and 36mm width fit standard electrical installations. Construction complies with EN/IEC 60947-2 standards and RoHS directives for safety and sustainability. Designed for residential and distribution overcurrent protection with AC earth leakage detection type.

Operating temperature range suits typical indoor environments and the device is padlockable for security.
