Schneider Electric Residual Current Circuit Breaker with Overload Protection 20A Current Rating 1-Pole 300 mA Trip A9DS5620

Schneider Electric A9DS5620 Residual Current Circuit Breaker with Overload Protection is engineered for reliable protection in residential and light commercial electrical installations. This device combines thermal-magnetic tripping technology with instantaneous earth-leakage sensitivity rated at 300 mA to prevent electrical hazards and ensure safe operating conditions.

The breaker features a compact 1-pole design with a 20A current rating, making it suitable for typical circuit protection requirements. Its DIN rail mounting capability facilitates straightforward installation in distribution boards.

It complies with internationally recognized standards such as RoHS and EN/IEC 60947-2, confirming its quality and safety performance. The tripping characteristics are classified as Type C, which is appropriate for moderate inrush currents in residential environments.

The breaker includes a toggle switch for user-friendly ON/OFF operation, along with a trip indicator for quick fault identification. Its breaking capacity of 4.5 kA ensures it can safely interrupt short circuits and overload conditions.

Designed for durability, the device supports up to 20000 switching cycles electrically and features a padlockable mechanism for added safety during maintenance. It functions reliably at ambient temperatures ranging from -5 °C to 60 °C and can withstand relative humidity of 95% at 55 °C.

With its tunnel terminal type and AC earth leakage protection, this residual current breaker provides efficient and effective circuit protection for electrical distribution systems.

Provides thermal-magnetic trip unit technology for overload and short circuit protection. Includes instantaneous earth-leakage protection with time delay for safety. Toggle switch actuator enables easy ON/OFF control with trip indicator.

Designed for DIN rail mounting and compatible with AC earth leakage protection type. Conforms to RoHS and EN/IEC 60947-2 standards ensuring quality and compliance. Compact dimensions: 85mm height, 73mm depth, 36mm width for efficient panel installation.

Breaking capacity of 4.5 kA to handle fault conditions effectively. Durable design rated for 20000 electrical operation cycles and padlockable for extra security. Able to operate under relative humidity of up to 95% at 55 °C ambient temperature.

Ideal for residential applications and overcurrent protection in distribution circuits. Explore more Schneider Electric products and reliable circuit protection devices at EnvMart to ensure safety and compliance in your electrical projects.
