Honeywell Technologies Roller Lever Micro Switch, Solder Terminal, 10.1A, 250 V, SPDT, IP40 ZM190G10F01

Honeywell ZM190G10F01 is a high-performance roller lever micro switch designed for precise switching operations in electrical, automation, and control applications. It features a solder terminal type connection for secure and reliable soldered joints, supporting a contact current of 10.1A at 250 volts AC in a compact single-pole double-throw (SPDT) configuration.

This subminiature micro switch from the ZM1 series incorporates a roller lever actuator that enables smooth mechanical engagement and consistent repeatability, making it ideal for limit-switching roles on small automated machinery and position sensing in electrical panels.

The micro switch operates reliably across a broad temperature range from -40°C to 125°C, suitable for various industrial environments. Its IP40 rated enclosure offers basic protection against solid particle ingress, making it intended primarily for indoor use where moisture and dust exposure are minimal. The housing is made of PBT material, ensuring electrical insulation and structural durability.

With mechanical life exceeding 50,000 cycles, this switch ensures reliable long-term operation in industrial and manufacturing applications. Electrical connections are made via solder terminals optimized for secure attachment on printed circuit boards or wire harnesses through soldering processes.

The ZM190G10F01 is certified under multiple global standards including RoHS, UL, CE, CQC, ENEC, and REACH directives, confirming its compliance with industry safety and environmental regulations. It is manufactured in China and belongs to Honeywell's trusted ZM1 series of micro switches.

Typical applications for this product include limit-switching functions in automated machinery, position detection within industrial control circuits, relay logic control systems, and panel-mounted detection roles.

The roller lever actuator ensures smooth and repeatable actuation performance. SPDT configuration allows flexible switching capabilities in control circuits. High rated contact current of 10.1A accommodates moderate electrical loads.

IP40 protection suitable for indoor environments with limited dust exposure. Wide operating temperature from -40°C to 125°C enables use in varied conditions. Durable PBT housing material provides mechanical strength and electrical insulation.

Long mechanical life rated at 50,000 minimum operations for industrial reliability. Solder terminals provide secure and reliable electrical connections. Compliance with RoHS, UL, CE, CQC, ENEC, and REACH standards. Manufactured in China, part of Honeywell's ZM1 Series.
