Eaton PFIM Series Residual Current Device 80A 4-Pole 30 mA Type AC 10 kA Breaking Capacity 230V, 400V 235418 PFIM-80/4/003-MW

Eaton 235418 PFIM-80/4/003-MW Residual Current Device is a compact professional series device designed to provide extra protection by detecting leakage currents in industrial electrical installations. With an 80 ampere current rating and 4 poles, it effectively safeguards electrical circuits by tripping at a 30 mA residual current.

This device features Type AC tripping characteristics suitable for alternating currents, making it ideal for industrial and commercial applications requiring precise fault detection. The device mounts conveniently on DIN rails, optimizing installation in control panels and switchboards.

Its breaking capacity of 10 kA ensures robust protection against short circuits and faults, with an instantaneous break time that quickly interrupts the current flow to prevent damage. The reset actuator is a toggle switch type, allowing easy manual reset after fault clearance.

Conforming to international IEC/EN 61008 safety standards, the product ensures reliable operation and safety compliance. The screw terminal connection type provides secure and stable wiring, with physical dimensions of 80 mm height, 65.5 mm width, and 70.5 mm depth fitting standard electrical enclosures.

The Eaton PFIM residual current device is manufactured in Romania and is suitable for industrial applications involving automation, electrical distribution, and safety equipment. Its electromagnetic tripping mechanism enables high performance and longevity in demanding environments.

Provides reliable residual current protection with 30 mA trip sensitivity. Type AC tripping characteristics ensure precise fault current detection. Designed for DIN rail mounting with a compact size of 80mm height, 65.5mm width, and 70.5mm depth.

Breaking capacity of 10 kA with instantaneous break time for rapid response. Features a toggle switch reset actuator and electromagnetic tripping mechanism. Compatible with rated AC voltages of 230 and 400 volts. Constructed according to IEC/EN 61008 standards for enhanced safety and reliability.

Equipped with screw terminal types for secure wiring connections.

This Residual Current Device is essential for protection in industrial electrical systems, ensuring enhanced safety by preventing electrical shocks and fire hazards. It is widely used in electrical distribution panels, industrial machinery, and automation control systems.
