Eaton PFIM Series Residual Current Device, 80A, 4-Pole, 300 mA Trip Sensitivity, Type AC, 10 kA 235420 PFIM-80/4/03-MW
Specifications
| Country of Origin | India |
|---|---|
| Range | PFIM |
| Brand | Eaton |
| Height | 80mm |
| Model | 235420 PFIM-80/4/03-MW |
| Depth | 70.5mm |
| Width | 65.5mm |
| Mount Type | DIN Rail |
| Current Rating | 80A |
| Series | PFIM |
| Terminal type | Screw |
| Breaking Capacity | 10kA |
| Number of Poles | 4 |
| Standards/Approvals | IEC/EN 61008 |
| Rated AC Voltage | 230, 400V |
| Tripping Characteristics | Type AC |
| Tripping Mechanism | Electromagnetic |
| Reset Actuator Type | Toggle Switch |
| Trip Sensitivity | 300mA |
| Break Time | Instantaneous |
Key Features
- Provides 4-pole protection with 300 mA trip sensitivity for reliable fault current detection.
- Type AC tripping characteristics suitable for alternating current applications.
- Breaking capacity of 10 kA ensures high fault interruption capability.
- DIN rail mounting enables easy installation in electrical panels.
- Electromagnetic tripping mechanism with instantaneous break time for fast response.
- Rated for AC voltages of 230V and 400V for versatile supply compatibility.
- Screw terminal type for secure electrical connections.
- Reset actuator is a toggle switch for convenient manual reset.
Product Description
Eaton 235420 PFIM-80/4/03-MW residual current device (RCD) is engineered for industrial and commercial electrical protection, offering an 80A current rating with 4 poles to protect circuits against earth leakage faults. The device features a 300 mA trip sensitivity, complying with Type AC tripping characteristics, ideal for alternating current fault detection.
This RCD supports DIN rail mounting for easy integration into standard electrical panels. Its compact build with dimensions of 80 mm height, 65.5 mm width, and 70.5 mm depth makes it suitable for space-constrained installations.
The PFIM series device incorporates an electromagnetic tripping mechanism with instantaneous break time, delivering rapid fault interruption up to 10 kA breaking capacity, enhancing safety in diverse electrical systems operating at 230 V and 400 V AC voltages. Screw terminals ensure robust and reliable connections, while the toggle switch reset actuator simplifies manual recovery after a trip.
Eaton's PFIM series RCDs are widely utilized in industrial automation systems, manufacturing plants, commercial electrical panels, and building safety installations where residual current protection is critical. The product adheres to IEC/EN 61008 standards ensuring compliance and performance reliability.
4-pole residual current protection with 80A current rating. 300 mA trip sensitivity providing extra fault protection. Type AC tripping suitable for alternating current faults. DIN rail mounting for modular panel fitting.
Instantaneous electromagnetic trip with high breaking capacity of 10 kA. Compact design for flexible installation. Rated for 230 V and 400 V AC operation. Robust screw terminals and toggle switch reset actuator.
This Eaton PFIM Residual Current Device is an essential safety component for electrical installations demanding reliable earth fault detection and fast disconnection in industrial and commercial environments. Browse similar Eaton circuit breakers and RCCBs at EnvMart for comprehensive electrical infrastructure solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 80A, providing adequate protection for electrical circuits against earth leakage faults.
It features a trip sensitivity of 300 mA, which enhances fault protection in electrical installations.
The Eaton PFIM-80/4/03-MW is rated for operation at both 230V and 400V AC, making it versatile for various supply systems.
It utilizes an electromagnetic tripping mechanism with instantaneous break time, ensuring rapid fault interruption to enhance safety.
The device has a breaking capacity of 10 kA, allowing it to handle high fault currents effectively.
It supports DIN rail mounting, which facilitates easy integration into standard electrical panels.
The dimensions are 80 mm in height, 65.5 mm in width, and 70.5 mm in depth, making it suitable for space-constrained installations.
It features screw terminals, ensuring secure and reliable electrical connections during installation.
It adheres to IEC/EN 61008 standards, ensuring compliance and performance reliability in electrical applications.
The reset actuator is a toggle switch, allowing for convenient manual reset after a trip event.
It is widely utilized in industrial automation systems, manufacturing plants, and commercial electrical panels where residual current protection is critical.
This model features Type AC tripping characteristics, making it suitable for alternating current fault detection.
