ABB Residual Current Circuit Breaker with Overload Protection 16A Current Rating 1-Pole 300 mA Trip 2CSR255080R3164

ABB 2CSR255080R3164 Residual Current Circuit Breaker with Overload Protection, part of the DS201 series, is engineered for effective protection of end-user single-phase electrical circuits against overload, short-circuit, and earth leakage faults. It features a robust thermal magnetic tripping mechanism that responds accurately to Type C tripping characteristics, making it ideal for residential, commercial, and light industrial applications.

This model operates at a rated AC voltage of 230V and includes a 16A current rating with a trip sensitivity fixed at 300 mA to ensure timely interruption during leakage events, enhancing user safety and minimizing fire hazards.

The compact design allows for installation on standard DIN rails and utilizes screw terminals for reliable and secure wiring connections. The device supports AC type earth leakage protection, effectively detecting sinusoidal alternating earth fault currents including both direct and indirect contacts, thereby preventing electrical shocks and equipment damage.

Its construction features a two-module width form factor with dimensions of 85mm in height, 69mm in depth, and 35mm in width, suitable for installations where space optimization is essential. The breaking capacity of 6kA provides ample protection against short-circuit currents, safeguarding electrical infrastructure from severe fault conditions.

Compliance with international standards IEC and RoHS guarantees product safety, quality, and adherence to environmental regulations, assuring users of its reliability and sustainable design.

Provides overload and short-circuit protection for single-phase circuits. Equipped with thermal magnetic tripping mechanism for reliable protection. Type C tripping characteristics suitable for general purpose applications.

Designed for DIN rail mounting with screw terminals for secure connections. Compact DS201 series with two-module width and 230V AC rated voltage. Breaking capacity of 6kA to handle fault currents effectively. Earth leakage protection of AC type to guard against earth faults.

Compact dimensions support space efficient installation. Conforms to IEC and RoHS quality and safety standards.

This Residual Current Circuit Breaker is widely used across industrial, commercial, and residential electrical distribution boards for enhanced safety and equipment protection. It plays a critical role in automation and electrical control systems by preventing electrical hazards and ensuring system reliability.
