ABB Residual Current Circuit Breaker with Overload Protection 16A Current Rating 2-Pole 30 mA Trip 2CSR272001R1164



Category Residual Current Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	DS200
Brand	ABB
Height	93mm
Model	2CSR272001R1164
Depth	69mm
Width	70mm
Standards	IEC/EN 60947-2
Current Rating	16A
Series	DS200
Terminal type	Busbar
Breaking Capacity	15kA
Number of Poles	2
Standards/Approvals	IEC/EN 60947-2, IEC/EN 61009-1, UL/CSA
Rated AC Voltage	230V ac
Tripping Characteristics	Type C
Tripping Mechanism	Short Circuit Protection
Reset Actuator Type	Lever
Trip Sensitivity	30mA
Earth Leakage Protection Type	AC
Operating Characteristic	Instantaneous

Key Features

Provides protection against overload and short-circuit currents.
Equipped with instantaneous operating characteristic for fast response.
Busbar terminal type ensures secure electrical connection.
Suitable for residential and commercial electrical installations.
Complies with IEC/EN 60947-2, IEC/EN 61009-1, and UL/CSA standards.
Compact dimensions of 70mm width, 93mm height, and 69mm depth.
Features lever-type reset actuator for easy manual control.
Breaking capacity of 15kA enhances electrical safety.

Product Description

The ABB 2CSR272001R1164 Residual Current Circuit Breaker with Overload Protection is engineered to safeguard electrical circuits by protecting against overload, short-circuits, and earth fault currents. This 2-pole breaker with a 16A current rating and 30mA trip sensitivity ensures reliable protection suitable for residential and light commercial applications. Its instantaneous operating characteristic enables it to react promptly to electrical faults, reducing risk of damage and ensuring electrical safety.

Featuring a robust busbar terminal system, it allows secure and reliable wiring connections. The unit complies with rigorous standards IEC/EN 60947-2, IEC/EN 61009-1, and UL/CSA, validating its high quality and performance. With a breaking capacity of 15kA, the breaker can handle short-circuit currents safely and efficiently.

Its compact form factor, with dimensions of 70mm width, 93mm height, and 69mm depth, allows easy installation within electrical panels without consuming excessive space. The lever-type reset actuator facilitates simple manual resetting after tripping events.

Designed specifically for use with 230V AC systems and AC type earth leakage protection, this breaker provides an effective safeguard against indirect and direct electrical contact risks, contributing to enhanced user and property safety.

Protects circuits from overload and short-circuit currents effectively. Instantaneous tripping characteristic ensures rapid fault response. High breaking capacity of 15kA for superior fault tolerance. Busbar terminal type supports stable and safe electrical connections.

Compact size suitable for residential and commercial panel installations. Lever reset actuator for convenient manual operation. Certified to international standards IEC/EN 60947-2, IEC/EN 61009-1, and UL/CSA. Earth leakage protection for enhanced safety against electrical shocks.

This product is an essential device for electrical safety in home and industrial installations, ensuring circuit reliability and protection from electrical hazards. Explore more electrical protection devices and accessories in the Electronics & Electricals category at EnvMart.
