Schneider Electric Residual Current Circuit Breaker with Overload Protection 16A Current Rating 1-Pole 30 mA Trip A9DG3616
Specifications
| Country of Origin | Spain |
|---|---|
| Range | Acti9 |
| Brand | Schneider Electric |
| Height | 85mm |
| Model | A9DG3616 |
| Depth | 73mm |
| Width | 36mm |
| Mount Type | DIN Rail |
| Current Rating | 16A |
| Series | A9 |
| Terminal type | Screw |
| Breaking Capacity | 6kA |
| Number of Poles | 1 |
| Standards/Approvals | IEC, RoHS |
| Rated AC Voltage | 230V ac |
| Tripping Mechanism | Thermal Magnetic |
| Trip Sensitivity | 30mA |
| Earth Leakage Protection Type | Type A |
Key Features
- Equipped with thermal magnetic tripping mechanism for reliable protection.
- Mounts easily on DIN rail for flexible installation.
- Rated AC voltage of 230V ac suitable for typical electrical distribution.
- Breaking capacity of 6kA ensures effective fault interruption.
- Compact dimensions of 85mm height, 73mm depth, and 36mm width.
- Type A earth leakage protection providing advanced sensitivity.
- Screw terminal type ensures secure wiring connections.
- Conforms to IEC and RoHS standards for safety and environmental compliance.
Product Description
Schneider Electric model A9DG3616 is a Residual Current Circuit Breaker with Overload Protection designed for industrial and commercial electrical distribution systems. This device supports a 16A current rating with a 1-pole configuration, delivering safe and reliable protection against earth leakage and overload faults.
Featuring a thermal magnetic tripping mechanism, the breaker offers dependable fault interruption and prolonged equipment protection. Its 30 mA trip sensitivity and Type A earth leakage protection classify it for sensitive electrical systems requiring enhanced safety measures.
The compact unit mounts on DIN rails for easy integration within control panels and switchboards. It operates at a rated AC voltage of 230V ac and has a robust breaking capacity of 6kA, capable of safely interrupting high-fault currents without damage.
With dimensions of 85mm height, 73mm depth, and 36mm width, it maintains a small footprint to optimize space in electrical assemblies. The device uses secure screw terminals for reliable wiring connections during installation.
Constructed to IEC and RoHS standards, this circuit breaker emphasizes safety and environmental sustainability. It is manufactured in Spain, reflecting Schneider Electric's commitment to quality and performance.
Thermal magnetic tripping mechanism for overload and fault protection. DIN rail mounting type for versatile panel installation. 230V AC rated voltage suited for common electrical systems. 6kA breaking capacity that ensures safe interruption of fault currents.
Type A earth leakage protection with 30 mA sensitivity. Screw terminal connection type for secure wiring. Compact design with precise dimensions for efficient use of space. Compliance with IEC and RoHS standards. Made in Spain ensuring reliable manufacturing standards.
This Residual Current Circuit Breaker is ideal for use in electrical distribution panels within industrial, commercial, residential, and HVAC applications. It safeguards personnel and equipment from electric shock and fire hazards caused by earth faults, making it essential for modern electrical installations.
Explore further Schneider Electric electrical protection devices and accessories on EnvMart for comprehensive industrial and commercial electrical safety solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 16A, making it suitable for various electrical distribution applications.
It has a breaking capacity of 6kA, which ensures effective interruption of fault currents.
This unit is designed for DIN rail mounting, allowing for flexible installation within control panels and switchboards.
The rated AC voltage for this circuit breaker is 230V ac, suitable for typical electrical distribution systems.
It features a trip sensitivity of 30 mA, providing advanced sensitivity for earth leakage protection.
This model offers Type A earth leakage protection, which is suitable for sensitive electrical systems.
The dimensions of this circuit breaker are 85mm in height, 73mm in depth, and 36mm in width, allowing for a compact installation.
It uses screw terminals, ensuring secure wiring connections during installation.
The device conforms to IEC and RoHS standards, emphasizing safety and environmental compliance.
It employs a thermal magnetic tripping mechanism for reliable protection against overload and fault conditions.
This circuit breaker is ideal for use in electrical distribution panels within industrial, commercial, residential, and HVAC applications.
It is manufactured in Spain, reflecting Schneider Electric's commitment to quality and performance.
