KNITTER-SWITCH MPB Series Miniature Push Button Switch, Momentary, PCB Mount, DPDT, IP40/IP67 Rated, 100V AC MPBS-22H01-F14
Specifications
| Country of Origin | China |
|---|---|
| Brand | KNITTER-SWITCH |
| Model | MPBS-22H01-F14 |
| IP Rating | IP40, IP67 |
| Mount Type | PCB |
| Series | MPB |
| Maximum Operating Temperature | 120°C |
| Contact Configuration | DPDT |
| Switch Configuration | On-Off |
| Minimum Operating Temperature | -10°C |
| Terminal type | PCB Pin |
| Standards/Approvals | UL, CSA |
| Switch Operation | Momentary |
| Actuator Colour | Silver |
| Contact DC Voltage | 100V |
| Actuator Style | Plunger |
| Switch Contact Current | 1A |
| Contact AC Voltage | 100V ac |
Key Features
- The switch features a silver plunger actuator for reliable performance.
- It supports both IP40 and IP67 ingress protection ratings for versatile applications.
- The contact voltage rating is 100 V AC and DC, suitable for low voltage circuits.
- Designed for a switch contact current of 1A, it ensures durability and safety.
- The switch operates within a temperature range of -10°C to 120°C.
- UL and CSA standards are met for quality and safety compliance.
- Its mechanical life includes at least 30,000 operations, ensuring long-term reliability.
- This miniature push button is ideal for PCB mounting in industrial and automation systems.
Product Description
KNITTER-SWITCH MPBS-22H01-F14 is a high-quality miniature push button switch from the MPB Series, designed for momentary switch applications with double pole double throw (DPDT) contact configuration. This switch is engineered for PCB mounting, making it convenient for compact industrial and automation circuit designs.
The actuator features a silver plunger style that provides tactile response and durability. The IP40 and IP67 ratings make the switch suitable for environments where protection against dust and moisture ingress is required, extending its usability across a wide range of industrial conditions.
Rated for 100 V AC and DC contact voltages with a current capacity of 1A, it is well-suited for low-voltage control systems. The operating temperature range from -10°C to 120°C ensures reliable operation in various environmental conditions. Compliance with UL and CSA standards attests to its adherence to safety and quality.
This switch guarantees a mechanical life of a minimum of 30,000 operations, supporting long-term usage without failure. Its design includes silver-plated terminals and contacts for dependable connectivity and performance.
Applications include industrial automation, electrical equipment, control panels, and PCB-based switching where compact miniature push buttons are essential. The robust IP ratings permit its use in harsher environments, such as manufacturing and machinery controls.
The switch offers momentary operation with DPDT contact configuration. It includes silver plunger actuator for durable operation. IP40 and IP67 ratings ensure protection against dust and moisture. Rated at 100 V AC/DC with 1A contact current capacity.
Supports a wide temperature range from -10°C to 120°C. Complies with UL and CSA standards for quality and safety. Has a mechanical life rating of 30,000 operations minimum. Ideal for PCB mounting in industrial automation and control systems.
Explore more industrial switch solutions and push button switch components at EnvMart for advanced electrical system designs.
Explore more products in our Push Button Switches & Components category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model features a double pole double throw (DPDT) contact configuration, suitable for various switching applications.
The switch is rated IP40 and IP67, providing protection against dust and moisture ingress for versatile applications.
It can operate at a maximum temperature of 120°C, making it suitable for a range of environmental conditions.
The switch has a contact current rating of 1A, which is appropriate for low voltage circuits.
Yes, it complies with UL and CSA standards, ensuring quality and safety in its applications.
This model is designed for PCB mounting, making it ideal for compact circuit designs in industrial applications.
The minimum operating temperature is -10°C, allowing for reliable performance in colder environments.
It features a silver plunger actuator, which provides tactile feedback and durability during operation.
The switch has a mechanical life rating of at least 30,000 operations, ensuring long-term reliability.
It supports contact voltages of 100V AC and 100V DC, suitable for low voltage control systems.
This model includes PCB pin terminals for easy integration into circuit boards.
It is suitable for industrial automation, electrical equipment, control panels, and PCB-based switching where compact designs are essential.
