Littelfuse Chassis Automotive Relay 24V DC Coil Voltage 300A Switching Current SPDT 880088
Specifications
| Country of Origin | Mexico |
|---|---|
| Brand | Littelfuse |
| Operating Temperature Range | -50°C to +105°C |
| Model | 880088 |
| Mount Type | Chassis |
| Contact Material | Silver Alloy, Copper |
| Series | HD |
| Maximum Operating Temperature | 105°C |
| Contact Configuration | SPDT |
| Minimum Operating Temperature | -50°C |
| Switching Current | 300 A |
| Shock Resistance | 10 G |
| Vibration resistance | 8 G |
| Terminal type | Wire |
Key Features
- Designed for high-amperage vehicle circuits with 300A continuous and 1500A inrush capacity.
- Bi-stable (latched) operation minimizes continuous current draw.
- Sealed to IP67 for outdoor installation durability.
- Supports operating temperature range from -50°C to 105°C.
- Compact chassis mount with silver alloy and copper contact materials.
- Equipped with wire terminal type for easy installation.
- Shock resistance of 10 G and vibration resistance of 8 G.
- Utilizes industry standard Deutsch DT06-6S connector.
Product Description
Littelfuse 880088 chassis automotive relay offers robust performance with a 24V DC coil voltage and 300A switching current rating. This relay features a SPDT contact configuration and is designed for high current demands in automotive and heavy vehicle applications.
The HD series bi-stable relay ensures extremely efficient operation by eliminating continuous current draw in both on and off states, thereby reducing battery load. Rated to handle 300A continuous current and 1500A inrush current for up to 10 seconds, it supports heavy-duty intermittent and continuous loads.
Constructed with silver alloy and copper contacts, this relay is chassis-mounted and equipped with wire terminals. It operates reliably across a wide temperature range from -50°C to +105°C, sealed to IP67 to withstand harsh outdoor environments and has shock resistance of 10 G and vibration tolerance up to 8 G. The relay uses the industry standard Deutsch DT06-6S connector for secure connections.
Its compact and rugged construction makes it suitable for industrial, agricultural, military, mining, and construction vehicle installations. The design eliminates the need for heavy gauge cabling by allowing the relay to be mounted close to the battery and controlled remotely, improving system efficiency and reducing cost.
Designed for high-amperage vehicle circuits with 300A continuous and 1500A inrush capacity. Bi-stable (latched) operation minimizes continuous current draw. Sealed to IP67 for durability in harsh environments. Wide operating temperature range from -50°C to 105°C.
Silver alloy and copper contact materials ensure reliable conductivity. Wire terminal type for flexible connectivity. Shock resistance of 10 G and vibration resistance of 8 G. Compatible with Deutsch DT06-6S connectors. Applicable in heavy vehicles, agriculture, military, mining, and construction sectors.
Discover a range of Littelfuse Automotive Relays and related components in the Electronics & Electricals category at EnvMart, designed to meet demanding industrial and automotive requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum switching current for this automotive relay is 300A.
This model operates at a coil voltage of 24V DC.
It supports an operating temperature range from -50°C to +105°C.
The relay features a Single Pole Double Throw (SPDT) contact configuration.
This model is designed for chassis mounting.
The contacts are made of silver alloy and copper materials.
It has an inrush current capacity of 1500A for up to 10 seconds.
It is equipped with wire terminals for flexible connectivity.
The relay has a shock resistance of 10 G and vibration resistance of 8 G.
Yes, it is sealed to IP67, making it suitable for outdoor installation durability.
This relay is applicable in heavy vehicles, agriculture, military, mining, and construction sectors.
It utilizes the industry standard Deutsch DT06-6S connector for secure connections.
