ABB System Pro M Compact S200 Miniature Circuit Breaker, 4-Pole, 63A, Type Z, 440V AC 2CDS254001R0608 S204 Z 63A - 10 KA

ABB 2CDS254001R0608 S204 Z 63A - 10 KA System Pro M Compact S200 Miniature Circuit Breaker is a 4-pole device engineered for protection against overloads and short circuits in electrical circuits. It offers a high current rating of 63A, suitable for residential, commercial, and industrial electrical installations.

This miniature circuit breaker incorporates advanced thermal and electromagnetic tripping mechanisms ensuring reliable operation under fault conditions. The type Z tripping characteristic makes it ideal for applications requiring high sensitivity and precise protection.

With rated voltages of 440V AC and 110V DC, this breaker supports diverse power sources. Its compact form factor measures 88mm in height, 70mm in width, and 69mm in depth, enabling efficient space utilization in electrical panels. The mounting is facilitated via a standard DIN rail, and connections are secured by screw terminals.

The device complies with internationally recognized standards IEC/EN 60664-1, IEC/EN 60898-1, IEC/EN 60947-2, and UL 1077, guaranteeing industrial quality and safety. It has an electrical endurance of 20,000 AC cycles, reflecting its durability and long service life.

Protection ratings IP20 and IP40 (in enclosure with cover) provide safeguards against ingress of solid objects and water, suitable for various installation environments. As part of ABB’s Better World line, this breaker is designed for easy disassembly, promoting sustainability through eco-friendly manufacturing practices.

This product is manufactured in Germany, ensuring strict quality controls and performance standards. Its 20 kA breaking capacity offers robust fault interruption capability to protect electrical systems effectively.

Designed for DIN rail mounting with screw terminal type for secure connections. Rated AC voltage of 440V and DC voltage of 110V for versatile applications. Equipped with thermal and electromagnetic tripping mechanisms for overload and short-circuit protection.

Complies with IEC/EN 60664-1, IEC/EN 60898-1, IEC/EN 60947-2, and UL 1077 standards for safety and reliability. Dimensions: Height 88mm, Width 70mm, Depth 69mm for compact installations. Electrical endurance of 20,000 AC cycles for long service life.

Better World product designed for disassembly promoting sustainability. Explore more high-quality and reliable Miniature Circuit Breakers and electrical protection devices in EnvMart's Electronics & Electricals section.
