ABB System Pro M Compact S200 Miniature Circuit Breaker 3+N-Pole 16A Type Z 440V AC 110V DC 6kA Breaking 2CDS253103R0468

Free Delivery in India | Lowest Global Shipping Charges

ABB System Pro M Compact S200 Miniature Circuit Breaker 3+N-Pole 16A Type Z 440V AC 110V DC 6kA Breaking 2CDS253103R0468



Category Miniature Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Germany
Range	System Pro M Compact
Brand	ABB
Height	88mm
Model	2CDS253103R0468
Depth	69mm
IP Rating	IP40, IP20
Width	70mm
Mount Type	DIN Rail
Current Rating	16A
Series	S200
Terminal type	Screw
Breaking Capacity	6kA
Number of Poles	3+N
Standards/Approvals	IEC/EN 60947-2 UL 1077
Rated AC Voltage	440V ac
Rated DC Voltage	110V dc
Tripping Characteristics	Type Z
Better World Claim	Designed for Disassembly
Tripping Mechanism	Thermal, Electromechanic

Key Features

This breaker features 3+N poles suitable for multi-phase applications.
Rated for 16 amperes current with type Z tripping characteristics.
Supports rated AC voltage up to 440 volts and DC voltage up to 110 volts.
Offers a breaking capacity of 6 kiloamperes ensuring high fault current interruption capability.
Designed for DIN Rail mounting with screw type terminals for secure connections.
Suitable for industrial and commercial circuits requiring IP40 and IP20 ingress protection.
Thermal and electromechanic tripping mechanism provides overload and short circuit protection.
Compact dimensions of 88mm height, 70mm width, and 69mm depth enable space saving in panels.

Product Description

ABB 2CDS253103R0468 System Pro M Compact S200 Miniature Circuit Breaker is engineered for dependable protection in electrical installations with 3+N poles and a current rating of 16A.

This MCB operates with type Z tripping characteristics, making it suitable for sensitive electronic circuits. It supports rated voltages of 440V AC and 110V DC, ensuring versatile application across various power systems.

The breaker features a breaking capacity of 6kA, making it capable of safely interrupting high short circuit currents. Its dual tripping mechanism combines delayed thermal tripping for overload and electromechanic tripping for instant short circuit protection, enhancing system safety and reliability.

Designed for easy installation on DIN rails, it incorporates screw type terminals for secure cable connections. The device provides IP40 and IP20 protection levels, suitable for industrial environments requiring dust and contact protection.

Compact in size with dimensions of 88mm height, 70mm width, and 69mm depth, it optimizes space in electrical panels and distribution boards. Compliant with IEC/EN 60947-2 and UL 1077 standards, this MCB meets rigorous international safety and performance requirements.

Manufactured in Germany under the ABB brand, it also carries the Better World designation, emphasizing sustainability through design for disassembly. This breaker features 3+N poles suitable for multi-phase power protection.

It has a 16A current rating with type Z tripping for enhanced selectivity. The rated AC voltage is 440 volts; DC voltage 110 volts for diverse applications. Breaking capacity of 6kA supports high short circuit current interruption capability.

Thermal and electromechanic tripping mechanisms provide comprehensive protection. DIN Rail mountable with screw terminals ensures installation ease and reliability. Compact dimensions save valuable panel space. IP40 and IP20 ingress protection levels suit harsh industrial environments.

Conforms to widely recognized IEC/EN and UL safety standards. Eco-friendly Better World product, designed for disassembly and sustainability.

This Miniature Circuit Breaker is ideal for industrial, commercial, and automation applications requiring high reliability and safety. Available from EnvMart’s comprehensive electrical protection portfolio, it enables efficient power system management and safeguards connected equipment.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

This miniature circuit breaker has a current rating of 16A.

It supports a rated AC voltage of 440V and a rated DC voltage of 110V.

The breaking capacity of this model is 6kA, allowing it to safely interrupt high short circuit currents.

This unit is designed for DIN Rail mounting, which facilitates easy installation in electrical panels.

It features a dual tripping mechanism that includes thermal tripping for overload protection and electromechanic tripping for short circuit protection.

The dimensions of this miniature circuit breaker are 88mm in height, 70mm in width, and 69mm in depth.

This circuit breaker has an IP40 and IP20 ingress protection rating, suitable for industrial environments.

It complies with IEC/EN 60947-2 and UL 1077 standards, ensuring it meets rigorous safety and performance requirements.

This model features 3+N poles, making it suitable for multi-phase applications.

This breaker is designed for disassembly, emphasizing sustainability in its design and manufacturing process.

It uses screw type terminals for secure connections, ensuring reliable installation.

It is suitable for industrial, commercial, and automation applications requiring high reliability and safety.
