ABB System Pro M Compact S200 Miniature Circuit Breaker, 3-Pole, 60A, Type K, 400V AC, 110 V DC, 6 kA 2CDS253001R0587

ABB 2CDS253001R0587 System Pro M Compact S200 Miniature Circuit Breaker is a high-performance protective device engineered for industrial and commercial control systems.

It provides three-pole overcurrent protection by combining delayed thermal tripping to manage overloads and an electromechanical mechanism for rapid short-circuit interruption. Designed for DIN rail installation, it offers space-saving compact dimensions of 88 mm height, 52.5 mm width, and 69 mm depth, suitable for panel layouts requiring flexibility.

This circuit breaker features a 60A current rating and type K tripping characteristic, making it well-suited for motor feeder protection and distribution board safeguarding, especially in light industrial environments. Its 6 kA breaking capacity limits fault energy, enhancing system safety under fault conditions.

The device supports AC voltages up to 400V and DC voltages up to 110V, making it versatile for different applications. Screw terminal connections accommodate flexible, ferruled, or rigid conductors up to 35 mm² and support busbar connections, ensuring secure and reliable wiring.

A bi-directional cylinder-lift terminal design enhances connection security and flexibility. The built-in red/green contact position indicator clearly shows ON/OFF status, and the actuator can be sealed to prevent unauthorized tampering, improving operational reliability.

Rated to withstand industrial vibrations and shock, the breaker operates effectively within a temperature range of -25°C to +55°C. It complies with international safety standards IEC/EN 60947-2, UL1077, and IEC/EN 60898-1, assuring users of its certified quality and durability.

Manufactured in Germany as part of ABB's Better World product line, it is designed for disassembly, supporting sustainability and environmental responsibility.

This Miniature Circuit Breaker is ideal for motor-feeder protection in automation panels, safeguarding control circuits requiring DC rating, and retrofit replacements where 3-pole 6 kA capacity is necessary.

60A current rating provides effective circuit protection under load. Type K tripping enhances motor feeder compatibility. 6 kA breaking capacity limits prospective fault energy. DIN rail mounting supports flexible installation.

Screw terminals accommodate conductors up to 35 mm². Red/green indicator shows ON/OFF status clearly. Electromechanical tripping enables fast fault interruption. Operates between -25°C and +55°C for industrial environments.

Complies with IEC, UL, and EN standards for safety and reliability. Manufactured in Germany with sustainability in mind.
