ABB System Pro M Compact S200 Miniature Circuit Breaker, 3-Pole, 30A, Type K, 400V AC, 110V DC, 6 kA 2CDS253001R0527

ABB 2CDS253001R0527 System Pro M Compact S200 Miniature Circuit Breaker is a robust 3-pole electrical protection device rated at 30A with Type K tripping characteristics, designed to protect three-phase installations from overload and short circuits. It operates at rated AC voltage of 400V and rated DC voltage of 110V and offers a breaking capacity of 6 kA.

This Miniature Circuit Breaker is built for industrial and commercial applications requiring reliable motor starter protection and distribution board safety. It features a delayed thermal element for overload conditions combined with an electromechanical trip for instantaneous short circuit interruption, allowing selective protection in low-voltage systems.

The device mounts easily on standard DIN rails (TH35-15 or TH35-7.5) with screw terminals using a cylinder-lift design, accommodating conductor sizes up to 35mm². The electromechanical thermal trip mechanism separates responses for overloads and short circuits, and a visual red ON/green OFF indicator provides clear operational status.

ABB's S200 series breaker offers durability with 20,000 electrical operation cycles and complies with UL 1077 and IEC/EN 60947-2 standards. It can operate in harsh environments with IP20 protection, extendable to IP40 with a protective cover, and withstands temperature variations from −25°C to +55°C and industrial vibration and shock levels.

This circuit breaker is ideal for motor starter protection in manufacturing plants, distribution boards in commercial buildings, retrofit upgrades on TH35 DIN rails, and control systems operating on 110V DC supplies. The product contributes to sustainability efforts through its design for disassembly, aligning with ABB's Better World product initiative.

Equipped with Type K characteristic for enhanced inrush current handling. Rated for 400V AC and 110V DC operating voltages. Breaking capacity of 6 kA ensures effective fault interruption. Designed for DIN rail mounting with secure screw terminal connections.

Features electromechanical, thermal trip mechanism combining overload and short circuit protection. Visual red/green indicator shows switch position clearly. Meets international standards UL 1077 and IEC/EN 60947-2. Operates reliably within temperature range −25°C to +55°C.

Offers IP20 protection in standard mounting and IP40 with cover for harsh industrial environments. Manufactured in Germany adhering to high quality and safety requirements. Discover more high-performance circuit breakers on EnvMart designed for electrical, industrial automation, manufacturing, and commercial building applications.
